What Paxeer X Network is

Paxeer X Network is one network with two execution domains: the Paxeer X chain (paxd, Go, EVM chain ID 125) and the LayerX kernel (layerxd, C17), the deterministic execution and accounting domain for autonomous agents. Official site: paxeer.network. Documentation: docs.paxeer.app.

The Paxeer X chain runs EVM execution on Tendermint consensus and carries the layerxcustody, layerxexchange, layerxbridge and launchpad modules, which contracts reach through the precompiles at 0x1013, 0x1015, 0x1016 and 0x1017. The LayerX kernel executes and accounts for agent activity deterministically and returns a signed receipt for each activity; its checkpoints settle on the chain through the layerxAnchor precompile at 0x1014.

This repository is the Sidiora Labs monorepo for Paxeer X Network: the Paxeer X chain and the LayerX kernel in one repository. Co-location keeps the kernel, the chain, contracts, and developer surfaces auditable in one place. Each subsystem keeps its own build, release, deployment, and trust boundary. The governing specification is spec/paxeer-x/spec.kvx, rendered as spec/paxeer-x/design.md; release notes are in CHANGELOG.md.

Try the network

The limited beta has not opened yet. The gateway API becomes available when it does. This is a mainnet beta on real value, so there is no faucet for general use; approved developers receive test allocations from the team.

To connect to the Paxeer X chain (chain ID 125), use one of the public JSON-RPC names listed in docs/site/docs/reference/public-rpc.md. The public endpoint checklist is docs/wiki/Getting-Started-Beta.md. The wallet, funding, and payments path is docs/wiki/PaymentsQuickstart.md. Assets: docs/wiki/Assets.md. RPC methods: docs/wiki/PublicRpc.md. Commitment levels: docs/wiki/CommitmentLevels.md. Public payment API: docs/wiki/PublicAPI.md.

Kernel developers start at the hosted documentation at docs.paxeer.app; the local cluster walkthrough is docs/wiki/Quickstart.md.

Build from source

The Paxeer X chain node is Go 1.25.6 (go.mod). The LayerX kernel is C17 (-std=c17 in the root Makefile). Agent, human, and platform workspaces use Rust 1.91.1 (rust-toolchain.toml). The kernel settlement contracts in contracts/ use Solidity 0.8.27 (foundry.toml). Replay qualification needs GCC 13, Clang 18, Docker, an amd64 musl runner, and an AArch64 cross-compiler plus QEMU; see docs/QUALIFICATION.md.

LayerX kernel targets:

make build
make test
make test-contracts
make ci

Paxeer X chain targets (paxd, defined in chain.mk), without changing directories:

make paxeer-build
make paxeer-lint
make paxeer-test
make paxeer-ci

make ci runs public-audit, kernel tests, a two-build archive comparison, consensus symbol checks, and sanitizer suites. make monorepo-ci is a separate cross-subsystem gate. A local pass is not authorization to deploy contracts, move custody, or handle real assets.

Repository layout

Documentation

• Hosted documentation: docs.paxeer.app
• Wiki index: docs/wiki/Home.md
• Getting started: docs/wiki/Getting-Started-Beta.md
• Payments developer path: docs/wiki/PaymentsQuickstart.md
• Public JSON-RPC: docs/wiki/PublicRpc.md
• Assets and tokens: docs/wiki/Assets.md
• Commitment levels: docs/wiki/CommitmentLevels.md
• Monorepo layout and release tags: docs/MONOREPO.md
• Qualification gates: docs/QUALIFICATION.md
• Specification: spec/paxeer-x/spec.kvx
• Release notes: CHANGELOG.md

SDKs and integrations

layerx-agentd is agent/crates/layerx-agentd. The MCP server is agent/crates/layerx-mcp. The developer CLI in platform/cli installs those transports with layerx install mcp and layerx install a2a.

Architecture

Paxeer X Network is one network with two execution domains: the Paxeer X chain node (paxd, Go) and the LayerX kernel (layerxd, C17), joined by EVM precompiles on one side and hosted platform services on the other. Rounded boxes are running services, cylinders are durable stores, hexagons are contracts and EVM precompiles (labelled with their address), and plain boxes are modules inside a state machine. Arrows follow the direction data moves: solid arrows submit or write, dotted arrows carry reads, events and proofs.

flowchart TB
  subgraph users ["Users and agents"]
    direction TB
    human(["Human"])
    agent(["Autonomous agent"])
    web("Human web app")
    hsvc("layerx-human-service")
    intents("layerx-intents
typed intent compiler")
    kms("layerx-human-kms")
    mcp("layerx-mcp")
    sdk("layerx-sdk
Rust · TypeScript · Python")
    agentd("layerx-agentd")
  end

  subgraph platform ["Platform services"]
    direction TB
    gateway("layerx-gateway
eth_* relay · px_* · px_getCapabilities")
    indexer("layerx-indexer
LayerX and Paxeer ingesters")
    idxdb[("SQLite history")]
    relay("relay/archive node")
  end

  subgraph lx ["LayerX kernel · C17"]
    direction TB
    layerxd("layerxd
LNI server · sequencer")
    kernel["Activity kernel
module dispatch"]
    perps["perps · 6"]
    spot["spot · 10"]
    gov["governance · 7"]
    kbridge["bridge · 8"]
    ledger["402LXP ledger
sole balance writer"]
    alog[("Activity log")]
    guarantor("layerx-guarantor")
  end

  subgraph px ["Paxeer X node · paxd"]
    direction TB
    evm("EVM JSON-RPC
pax-geth")
    cons("Tendermint consensus")
    occ("OCC parallel executor")
    pAnchor{{"layerxAnchor
0x1014"}}
    pCustody{{"layerxCustody
0x1013"}}
    pExch{{"layerxExchange
0x1015"}}
    pBridge{{"layerxBridge
0x1016"}}
    pLaunch{{"launchpad
0x1017"}}
    mCustody["layerxcustody module"]
    mExch["layerxexchange module"]
    mBridge["layerxbridge module"]
    mLaunch["launchpad module"]
    paxdb[("PaxDB state store")]
  end

  subgraph eth ["Bridge to Ethereum"]
    direction TB
    relayer("layerx-bridge-relayer")
    vault{{"PaxeerXVault"}}
  end

  human --> web
  web -->|"HTTPS"| hsvc
  hsvc -->|"typed intent"| intents
  hsvc -->|"custody signing"| kms
  intents -->|"compiled Activity"| agentd
  agent --> mcp
  agent --> sdk
  mcp -->|"tool calls"| agentd
  sdk -->|"daemon socket"| agentd
  agentd -->|"LNI frames"| layerxd

  layerxd --> kernel
  kernel --> perps & spot & gov & kbridge
  kernel -->|"transfer sets"| ledger
  ledger -->|"signed receipt"| alog
  alog -->|"sealed batch"| guarantor
  guarantor -->|"submitCheckpoint"| pAnchor

  layerxd -.->|"batch sync"| relay
  relay -.->|"history batches"| indexer
  evm -.->|"blocks · logs · tx_search"| indexer
  indexer --> idxdb
  indexer -.->|"px_getHistory"| gateway
  layerxd -.->|"lx_* reads"| gateway
  gateway -->|"eth_* relay"| evm
  gateway -.->|"eth_call · eth_getLogs"| web
  gateway -.->|"px_* reads"| hsvc

  evm -->|"txs"| cons
  cons -->|"ordered blocks"| occ
  occ --> pAnchor & pCustody & pExch & pBridge & pLaunch
  pCustody --> mCustody
  pExch -->|"pending intent"| mExch
  pExch -->|"margin deposit"| mCustody
  pBridge --> mBridge
  pLaunch --> mLaunch
  occ -->|"state commits"| paxdb

  pExch -.->|"intent logs decoded"| intents
  mCustody -.->|"custody credit proof"| kbridge

  vault -.->|"Deposit event"| relayer
  relayer -->|"bridgeIn"| pBridge
  pBridge -.->|"BridgeOut event"| relayer
  relayer -->|"release"| vault

  classDef actor fill:#e4dcf2,stroke:#7a68ad,color:#2a2340
  classDef svc fill:#d8e5f3,stroke:#4d77a8,color:#1b2a3c
  classDef store fill:#e1ecd4,stroke:#6a8c48,color:#23321a
  classDef contract fill:#f3e2cc,stroke:#ad7a3e,color:#3b2913
  classDef module fill:#e6e8eb,stroke:#6b7480,color:#22272e

  class human,agent actor
  class web,hsvc,intents,kms,mcp,sdk,agentd,gateway,indexer,relay,layerxd,guarantor,evm,cons,occ,relayer svc
  class idxdb,alog,paxdb store
  class pAnchor,pCustody,pExch,pBridge,pLaunch,vault contract
  class kernel,perps,spot,gov,kbridge,ledger,mCustody,mExch,mBridge,mLaunch module

The bridge to Ethereum in detail: each relayer instance holds one attestor key behind a remote signer, journals every observed event and signed transaction before broadcast, and meets a signature threshold above one by exchanging signatures with other instances.

flowchart LR
  subgraph ethb ["Ethereum"]
    bVault{{"PaxeerXVault"}}
  end

  subgraph relb ["Relayer instance"]
    direction TB
    bRelayer("layerx-bridge-relayer")
    bSigner("Remote signer
one attestor key")
    bJournal[("Append-only journal")]
    bCosign[("Cosign directory")]
  end

  subgraph pxb ["Paxeer X node"]
    direction TB
    bPrec{{"layerxBridge
0x1016"}}
    bModule["layerxbridge module
attestors · caps · nullifiers"]
    bTf["tokenfactory
bridged denoms"]
  end

  bVault -.->|"Deposit event"| bRelayer
  bRelayer -->|"digest to sign"| bSigner
  bRelayer -->|"events · signed txs"| bJournal
  bRelayer -->|"threshold signatures"| bCosign
  bRelayer -->|"bridgeIn + signatures"| bPrec
  bPrec --> bModule
  bModule -->|"mint · burn"| bTf
  bPrec -.->|"BridgeOut event"| bRelayer
  bRelayer -->|"release + signatures"| bVault

  classDef svc fill:#d8e5f3,stroke:#4d77a8,color:#1b2a3c
  classDef store fill:#e1ecd4,stroke:#6a8c48,color:#23321a
  classDef contract fill:#f3e2cc,stroke:#ad7a3e,color:#3b2913
  classDef module fill:#e6e8eb,stroke:#6b7480,color:#22272e

  class bRelayer,bSigner svc
  class bJournal,bCosign store
  class bVault,bPrec contract
  class bModule,bTf module

Contributing

Read CONTRIBUTING.md before opening a pull request. Protocol changes start in spec/. Do not disclose a suspected vulnerability in a public issue; follow SECURITY.md.

Security

Report vulnerabilities through GitHub private reporting, as described in SECURITY.md.

License

Licensed under the Apache License, Version 2.0. See LICENSE and NOTICE.

Paxeer X Network is developed by Sidiora Labs. Source: github.com/Sidiora-Labs/Paxeer-X-Network.
