Vibing Steampunk (vsp)

AI-Agentic Development Unlocked for ABAP — any system with ADT enabled, 7.50 upwards. The available surface varies by release, and vsp compat reports it per system: RAP needs S/4, AMDP needs HANA, and some ADT resources present on S/4 are absent on ERP.

ADT ↔ MCP Bridge: Gives Claude (and other AI assistants) full access to SAP ADT APIs. Read code, write code, debug, deploy, run tests — all through natural language (or DSL for automation).

New in the last three releases — the part of a root cause that never fit in a tool:

• The MIME repository, byte-exact. Every file anyone uploaded through SMW0 — images, audio, a font, a game — read back whole. The bytes are a data cluster of 255-byte lines whose last line is padded, so the cluster cannot say where the file ends; filesize in WWWPARAMS can, and that is the step that makes it exact rather than nearly right. Nothing installed on the server.
• Cluster tables, decoded. BALDAT, INDX, STXL — every table an EXPORT ... TO DATABASE ever wrote — read over plain ADT and decoded here: SAP's LZH and LZC decompressed in Go, the cluster format walked, the fields named from DD03L. What only IMPORT could read, without a line of ABAP.
• A dump's own why — dumps --explain now reads the whole ST22 document, not just the stack: the message it raised with its variables, the system fields, the failing source line, and the runtime's chosen variables per frame — so a stale handle or an unresolved pointer is on screen, not dug out by hand.
• The application log with its messages, by object and date range, and the same log from a bare SE16H export of two tables.
• Spool and jobs — SP01's list decoded from TemSe, a job's steps and its log, exported for the whole night in one command.
• Where the settings are — a report's variants with the screen's own labels, SE37's saved test data, SE61 documentation as Markdown, and the IMG searched by title with the activity's transaction.
• Texts and the title, from the same call — selection texts and text symbols written as a plan with a diff, activated so they stay, and a hint after every program create that names the fields still without one; the description set without touching the source.
• vsp update — the release for this platform, verified against checksums.txt, renamed into place of the running binary, from the repository the binary was built for (--repo owner/name to point elsewhere).
• A response cache that turns a 4-second slim into 10 ms, on Go-native SQLite when it should outlive the process.

And still the one that started it: the whole ABAP debugger — breakpoints, attach, stepping, call stack and variables — through SAP's own ADT resources over a classic-RFC tunnel or a plain HTTPS session, with nothing installed on the server and no SAP SDK.

See also: OData ↔ MCP Bridge for SAP data access.

Want to review or test? Start here: Reviewer Guide — 11 hands-on tasks, 6 of them fully offline.

Hot Right Now

The ABAP Debugger over RFC — Nothing Installed on the Server

The debugger needs one thing above all: a stable ABAP session. attach_debuggee( ) returns an object reference, and step, stack, and variables all hang off it — which is why a debug loop spread over independent HTTP calls kept losing its debuggee. A pinned classic-RFC conversation is that session, natively, with no ICF, no CSRF, and no WebSocket upgrade.

vsp rfc debug                                    # one pinned session, held for the whole loop
dbg> ebp ZADT_DEBUG_LOOP 9                       # breakpoint, by object name — ADT resolves the URI
dbg> eclipse 120                                 # listen, attach, stack — through SAP's own ADT resources
dbg> elocals                                     # the stopped frame's variables, with values
dbg> estep over
dbg> estack

The same six commands work in vsp adt debug, over HTTPS, against a system with no gateway port. An integration test runs that script over both transports and fails if they disagree about where the debuggee stopped or what it could see (go test -tags=integration -run Conformance ./pkg/saprfc/).

From an MCP client the same loop is SetBreakpoint → DebuggerListen → DebuggerGetVariables → DebuggerStep → DebuggerDetach. DebuggerListen attaches for you: a debuggee is only attachable while it waits, so a caller that has to copy an id between two tool calls loses the race.

Nothing is installed on the server for this. eclipse drives the very resources Eclipse uses — /sap/bc/adt/debugger/listeners, /sap/bc/adt/debugger, /sap/bc/adt/debugger/stack — tunnelled through SADT_REST_RFC_ENDPOINT. The only reason a normal tool cannot use them is that ADT keeps the debug session in an ABAP roll area, reachable again only through a sap-contextid cookie; over a pinned RFC conversation the roll area is the session, so there is nothing to correlate. You get ADT's own answers back: source URIs per stack frame, DYNP screen frames, the authorization flags, the action catalogue — and SAP labels the session RFC session: itself.

No RFC channel at all? Then use vsp adt debug: the identical loop over one stateful HTTPS session. The debugger was never an RFC feature — listen, attach, stack and step are ADT resources, and RFC was one way to carry them. What they need is a session, and over HTTPS that is the stateful ICF session sap-contextid selects. Verified against A4H over plain HTTPS, with a cookie or a password and no gateway port in sight — which is the shape of every system where you can sign on to ADT but nobody will give you an RFC user (docs/design/http-only-systems.md).

Breakpoints need no ABAP either. POST /sap/bc/adt/debugger/breakpoints answers 200 on both transports and writes the same ABDBG_EXTDBPS row a Z facade would. One asymmetry is real: SAP answers the GET with 200 and an empty body, because in ADT the breakpoint set is the IDE's state — Eclipse posts it whole rather than asking. So a client keeps its own record, and adding one breakpoint is a read-modify-write.

There is also a typed, smaller-payload path over a little ABAP facade (abap/src/zadt_debug) for systems where the ADT debugger resources are absent or blocked — and for the one thing ADT will not answer, reading the server's own breakpoint table:

dbg> bp SAPLZADT_DEBUG/LZADT_DEBUGU01 9          # external breakpoint (name the include!)
dbg> catch 150                                   # wait for a hit, attach, show the stack
dbg> step over
dbg> stack
dbg> detach

Both paths are proven live on A4H: the breakpoint was hit by a function module called over a second RFC connection, the stack showed the real entry chain %_RFC_START → REMOTE_FUNCTION_CALL → the module, stepping walked it line by line, and afterwards the debuggee ran on and committed its work.

Variables are read and written. elocals walks the debugger's variable tree to the stopped frame's own data; eset LV_AMOUNT 900 puts a value back, and the next statement computes with it — measured on A4H, a value that arrived from the database as 46 became 901 downstream instead of 47. That turns the debugger into a scenario harness: reaching a state by arranging for the system to produce it is usually the hard part, and this skips it. It changes real execution, database writes included, so it is not something to do in somebody else's session without asking. eframe moves the cursor to another stack entry, so the caller's half of a call boundary is readable too.

Customer code by default. A breakpoint set in a SAP standard program is accepted, given an id, and then never fires: without system debugging there is nowhere to stop. That is SAP's behaviour, not a filter of ours — esys turns it on for the cases that need it. Staying out costs less than it sounds, because a breakpoint on the line that calls a standard module captures what went in, and one on the line after captures what came back.

It catches web requests. An external breakpoint fires for an ICF session just as it does for RFC: a function module triggered through /sap/bc/soap/rfc over plain HTTP was caught by a listener on an HTTPS debug session, with the whole web stack visible — %_HTTP_START → HTTP_DISPATCH_REQUEST → CL_HTTP_SERVER->EXECUTE_REQUEST → the SOAP handler → the module. An OData request is that same path with the Gateway handler, so debugging one needs nothing new.

The read half needs no ABAP either: vsp rfc debuggees, vsp rfc breakpoints and vsp rfc watch read ABDBG_ACTIVATION and ABDBG_EXTDBPS directly — who is parked in the debugger and where, short dumps included.

It is tested without a system. vsp adt debug --record captures a live session to a cassette — every request and every answer — and the tests replay it, so go test ./... drives the real debugger with no SAP, no RFC channel and no Z code. The committed cassettes are real 7.58 sessions: catching a stopped program, reading its stack, reading locals with their values, stepping into a subroutine and back out, writing a variable, expanding a structure and a table, and a statement-level trace. A recording is an oracle rather than a mock — nobody writes the answers, so nobody can write them to match the code, which is how four defects surfaced the first time it ran.

Because a cassette is taken from a live system, the recorder drops every header that carries a session and blanks the eight places a debug session names the application server, and a test re-checks the committed files on every run.

7.50 works too, and did not before. That release has no /sap/bc/adt/debugger/stack: the listener caught a debuggee, the attach succeeded, and the first stack read returned 404 — and since catching a debuggee ends with a stack read, every catch was thrown away. It serves the same document from the dispatcher instead. The shape is discovered once per session and remembered.

Debug from your editor (DAP)

vsp dap is a Debug Adapter Protocol server on stdin/stdout. VS Code, nvim-dap, JetBrains and other DAP clients can use it to set breakpoints in ABAP and step through it on a real system. It is the same debugger as vsp adt debug: SAP's own /sap/bc/adt/debugger* resources on one held stateful session, with nothing installed on the server.

• Logon: vsp's usual config (a .vsp.json system, or SAP_* env). The launch configuration names a system and a user, never a password.
• What it does: it arms your breakpoints and waits. Run the program in SAP (SE38, a unit test, an RFC call, a job) and the editor stops on the line. vsp never starts the program itself, and it is not an MCP tool.
• Breakpoints: set them in files named by vsp's export convention (zcl_x.clas.abap, zrep.prog.abap, zgrp.fugr.z_fm.abap, ...). Stack frames open the local file when it is under sourceRoot. Otherwise the source is read from SAP.
• Read-only systems: you can still debug, but you can't change variables.

VS Code: until the vsp extension ships, any extension can declare the adapter in its package.json. The launch.json entry then uses that type:

// package.json of a local extension
"contributes": {
  "breakpoints": [{ "language": "abap" }],
  "debuggers": [{ "type": "abap-sap", "label": "ABAP (vsp)", "program": "vsp", "args": ["dap"] }]
}

// .vscode/launch.json
{ "type": "abap-sap", "request": "attach", "name": "ABAP on A4H",
  "system": "a4h", "object": "ZVSP_DEBUG_DEMO", "sourceRoot": "${workspaceFolder}" }

nvim-dap:

local dap = require('dap')
dap.adapters.vsp = { type = 'executable', command = 'vsp', args = { 'dap' } }
dap.configurations.abap = {
  { type = 'vsp', request = 'attach', name = 'ABAP on A4H',
    system = 'a4h', object = 'ZVSP_DEBUG_DEMO', sourceRoot = '${workspaceFolder}' },
}

Launch and attach take the same arguments: system, user (whose debuggees to catch; the default is the logon user), object and include (optional, resolved at start), sourceRoot, systemDebugging and listenSeconds. Supported requests: breakpoints, continue, step over/in/out, the stack, and variables (locals, globals, and structures and tables expanded in place). Changing a variable is also supported.

AMDP debugging over plain ADT — the breakpoint fires

An AMDP method runs inside HANA, not inside ABAP, so debugging one means bridging two debuggers. ADT does that itself, and nothing has to be installed:

vsp adt debug -s a4h -c "astart; abp ZCL_MY_AMDP 41; aresume 12; astop"
# and, while it waits, run the method from anywhere

SAP answers ON_BREAK with the position inside the SQLScript. This project spent months concluding the opposite, through a Z service and a WebSocket protocol built to reach what the system was already offering.

With values. alocals lists everything in scope — scope, type, and for a table its handle and row count — and costs no request at all, because the stop event already carries it. avar LV_I reads what a variable holds:

output   ET_RESULT   table[0] handle 3000001
input    IV_COUNT    INTEGER
local    LV_I        INTEGER
→ LV_I    INTEGER    1

Reading a variable is asynchronous and does not advertise it: the resource answers 200 with an empty body and puts a request id in Location, which reads exactly like a variable that is out of scope. The value arrives through the same queue as everything else. Table contents are the one thing still missing — the address is right and HANA refuses to build its data provider from it; see AMDPTableRows for where it stands.

The trap is that answers arrive as a queue with acknowledgements at its head. Resume once, see SYNC_BREAKPOINTS, and you conclude the breakpoint never fired — while the debuggee is, at that moment, blocked on it. aresume waits past them, and reports SAP's verdict on the way (state="VALID"), because a refused breakpoint and a method that never ran look identical otherwise.

The whole choreography stays on one held session: the ADT resource keeps its handles in ABAP session memory, so a second connection finds nothing.

Reachable from an agent too: SAP(action="debug", target="AMDP_ADT_START").

Post-mortem: from a dump to what was logged around it

A debugger helps when you can reproduce the failure. Usually nobody can: there is a dump from Tuesday, a user who has moved on, and no way to make it happen again.

vsp -s a4h dumps --group                          # what keeps failing, not what failed once
vsp -s a4h dumps --similar latest                 # what else looks like this one, and how closely
vsp -s a4h dumps --explain latest --tolerance 10m # the why: message, failing line, stack, and the log around it
vsp -s a4h applog --program ZCL_ORDER_POST        # who logged what, and from where

--explain reads the one formatted document ST22 keeps and pulls the causal detail out of it — no extra round trips. Before the stack it prints the message the dump raised with its own variables (message SY 373 (type X) with -1), the system fields that frame it (SUBRC, FDPOS, PFKEY, TITLE), and the source line it died on with a line either side, the failing one marked. --json adds a detail object with the full systemFields, source, and the runtime's variables per stack frame — where a stale handle or an unresolved pointer shows up as its value. So the answer to "why" is on screen, not reconstructed by hand from the raw dump.

--group collapses dumps by runtime error and terminated program, which is structural. Grouping by "the same afternoon" would make a busy hour look like one incident.

--similar answers "is this new, and how often does it happen" on a ladder, and says which rung each match is on:

Rungs 2 and 4 come free with the listing. Rungs 1 and 3 need the failing line and the application component, which are in the dump detail and nowhere else, so they cost one fetch per candidate — bounded by --deep, and skipped entirely on a release that has the feed but not the detail resource. A rung is an argument, not a verdict: rung 4 is the same class of failure and is not the same bug, and the output says so on every row rather than in a footnote.

Two things the ladder refuses to do. Three different function groups on a live system all terminate at SAPMSSY1 line 36, because that is where the RFC entry point is — so the line alone is never rung 1 without the program. And custom code is usually assigned to no application component, which is reported as no neighbourhood rather than as one shared neighbourhood of everything unassigned.

--explain is the interesting one. Correlating a dump with the application log is a time join, and a time join is where a tool starts lying — two things in the same second is not causation. What rescues it is that a log entry records the program that wrote it. So time is the filter and the program is the reason:

Every row states its own argument, because the argument is what lets a person overrule the ranking. A match is a candidate; "the cause" is not ours to say.

One rung does not fire yet, and the tool says so rather than leaving a gap that looks like an answer: asking what a program calls needs /sap/bc/adt/cai/callgraph, which is advertised on none of 7.50, 7.57 or 7.58 and answers 404. The ranking is right and only the source of callees is missing; where-used over CROSS would supply it.

All of it over plain ADT — no RFC, no gateway, no Z code. SAP's own way into the application log is the BAL_* function group, which cannot be called remotely by any transport; the log's tables are ordinary tables, so free SQL reads them instead — the headers from BALHDR, and with --messages the messages from BALDAT, which is a cluster table and needs one more step:

vsp -s a4h applog --object ZDEMO_LOG --since 2026-09-01 --messages

2026-09-04 12:00:01  ZDEMO_LOG/POST  log 22274  TESTUSER  ZCL_DEMO_POST=================CP
    000001 E ZDEMO_MSG 017       20260904100001.5909840  Order 4711 has no delivery block
           context ZDEMO_ORDER_KEY: 0000004711

Jobs and spool — SM37 and SP01 as tables

A night job failed. vsp jobs list --since shows it with its status, its steps — program, variant, user — and the spool number each step wrote; vsp spool read prints that spool, and vsp spool export writes every matching request to a directory with an index of who wrote what, when, from which job. All of it from TBTCO, TBTCP, TSP01 and TST03 over free SQL: the spool content is the TemSe object decoded here — records, print controls, the list format's escapes — checked line for line against what XBP returns.

Two things are not tables. The job log is a TemSe object most systems keep in files, and so is spool on a system configured that way; both come over RFC through XBP, which vsp jobs log and --via rfc do. On the MCP side: job_list, job_log, spool_list, spool_read.

vsp -s a4h jobs list --program ZDEMO_NIGHTLY_RUN     # every job with a step running it
vsp -s a4h spool list --job ZDEMO_NIGHTLY --top 20
vsp -s a4h spool export --user TESTUSER --since 2026-09-01 --out ./spool

What is it set up to do — variants, test data, documentation, the IMG

The other half of a root cause is configuration, and it sits in tables too. vsp variants reads a report variant as a table of fields with their labels, kinds, types and values, from VARI and the program's selection texts; that is what a job's step selected, without RS_VARIANT_CONTENTS. vsp fmtest reads the Function Builder's saved test data from EUFUNC: every set's inputs, what came back, the runtime, the interface as it was. vsp docs renders SE61 documentation as Markdown, includes resolved — data elements, reports, function modules, classes, messages — and walks the IMG: docs img finds activities and folders by their titles and gives the path to each, docs activity gives the transaction and the activity's own text. MCP: variants, fm_test_data, documentation, img_search, img_activity.

vsp -s a4h variants ZDEMO_NIGHTLY_RUN                # the variants, who made them, when
vsp -s a4h variants ZDEMO_NIGHTLY_RUN MONTH_END --json
vsp -s a4h fmtest STRING_CONCATENATE
vsp -s a4h docs read DE BALLEVEL
vsp -s a4h docs activity /IWBEP/CP_DELETE_JOB

Selection texts and text symbols, without leaving the call

A selection text is maintained in a screen three clicks from the code, and a program created over MCP has none. vsp texts reads and writes the text pool over ADT — selection texts (S) and headings (H) of a program, text symbols (I) of a program or a class — and a write is a plan first: what is added, what changes from what, what is already so, what is refused (a key the screen does not have, a key SAP would reject, a text past 30 characters). Nothing is locked when nothing differs.

vsp -s a4h texts get ZDEMO_RUN                       # S, I and H entries
vsp -s a4h texts set ZDEMO_RUN P_DEVC="Package to scan" S_OBJ="Object names"
vsp -s a4h texts set ZDEMO_RUN --kind I 001="Nothing found"
vsp -s a4h texts set ZDEMO_RUN --dry-run P_DEVC="Package to scan"
vsp -s a4h texts set CLAS ZCL_DEMO --kind I 001="Loaded"
vsp -s a4h texts set ZDEMO_RUN --delete P_MODE            # the entry a removed field left behind

The text elements are their own ADT resource with their own lock; the lock, the write, the unlock and the activation happen in the one call. The activation matters: the PUT lands as an inactive version, and activating the program does not carry it — texts written without it read back unchanged from the active version and look lost. MCP: i18n with op: texts_get / op: texts_set, create PROGRAM takes a texts map, and after a program is created or written the result says which screen fields still have no text and which TEXT-xxx the source uses but never defines — with the call that sets them.

The description, and the binary itself

The description is the short text SE38 shows as the title and prints at the head of a list. Creating over ADT sets it once, from the file's header comment when deploying — and SE38's own template put *& Report ZDEMO there, which became the description of more than one program. The header line is skipped now, and the text can be set later without touching the source:

vsp -s a4h description ZDEMO_XFER                    # what it is
vsp -s a4h description ZDEMO_XFER "DPL snapshot transfer: download / upload / transplant"
vsp -s a4h description CLAS ZCL_DEMO "Demo class"    # PROG, INCL, CLAS, INTF, FUGR, FUNC, TABL, DDLS

MCP: edit with type: set_description, and a description on deploy_from_file and write_program is written after the source.

A write with no transport named used to leave the choice to SAP, which answered with a request of its own — Generated Request for Change Recording — one per write, so a day's work on one feature ended up spread over three requests beside the one already open. Now the write asks the transport check what Eclipse's dialog asks it: which of your open requests fit. The object's own request wins, then the one already holding objects of the package, then the only candidate, then the newest; with none and --enable-transports, one is created and the result says so. Every result carries transport and, when the choice was made here, transportNote. --transport-choice off (or SAP_TRANSPORT_CHOICE=off) restores the old behaviour.

A request filed under a CTS project. Systems that organise their requests in CTS projects expect each request to carry one. Where the project is mandatory, ADT refuses a request without it — Change requests must be assigned to a project — so vsp could not create a request there at all, and elsewhere it created one outside any project. --cts-project and --transport-target (SAP_CTS_PROJECT, SAP_TRANSPORT_TARGET, or cts_project / transport_target per system in .vsp.json) now apply to every request vsp creates, the automatic one above included; create_transport also takes cts_project and target per call. ADT's answer names the project by its external ID, not the name it stored — E070A (SAP_CTS_PROJECT) is the record.

Merging requests, moving an entry is SE09's Utilities → Reorganize and nothing in ADT — the organizer's resources add objects and release, none removes an entry — and the function modules behind SE09 are not remote-enabled. They are reachable through ZADT_VSP's CALL FUNCTION bridge, which now takes JSON for structure and table parameters and turns a dialog off when told to:

SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport merge TR-A TR-B --into TR-C     # tasks and objects move, sources are deleted
SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport move "PROG ZDEMO_RUN" --from TR-A --to TR-B

Adding an entry nobody edits -- a LIMU REPT for a report's texts, a TABU with the keys of the customizing rows it carries -- and taking one out go the same way:

SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport add TR-A "LIMU REPT ZDEMO" "R3TR PROG ZDEMO2"
SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport add TR-A "R3TR TABU ZDEMO_CONF" --key 100KEY1 --key "100KEY2*"
SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport remove TR-A "PROG ZDEMO"

MCP: system with merge_transports (source, target), move_transport_object (object, from, to), add_transport_object (transport, objects or object + keys) and remove_transport_object (transport, object). All need ZADT_VSP on the system — redeploy it after this release, the bridge changed.

A transport of copies of a request, the way SE01 builds one: the request is created over ADT (tm:type T, with a target), and its object list copied in with TR_COPY_COMM through the same bridge — from each task that holds objects while the request is modifiable, since the function copies only the entries of the request it is given, and from the request itself once it is released. The description defaults to ToC and the original's. ADT takes a target without a client (QAS, not SE01's QAS.100), or a target group. Nothing is released unless asked:

SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport toc TR-A --target QAS
SAP_ENABLE_TRANSPORTS=true vsp -s a4h transport toc TR-A --target /GROUP/ --release

MCP: system with copy_to_toc (transport, target, optional description, cts_project, release).

Under --allowed-packages, every object the copy would carry is checked first (a LIMU entry by its class, interface or program; one whose object cannot be told, such as LIMU FUNC, is refused), and any offender refuses the whole copy before anything is created. Entries a modifiable request holds itself, outside its tasks, are not copied; they are listed under skipped. If a list fails to copy or the release fails, the result is an error that names the transport of copies, what was copied, what was not, and the release status. --read-only refuses it like any transport write.

Upload a transport into the connected system's import queue -- and no further. A released request's cofile K. and data file R. are written into DIR_TRANS of the system vsp is connected to (cofiles/, data/), and the request is added to that system's import buffer, as STMS's Extras > Other Requests > Add does. vsp never imports: the import stays a human step in STMS.

SAP_ENABLE_TRANSPORTS=true vsp -s qassys transport upload --cofile ./K900123.DEV --datafile ./R900123.DEV   # waits up to --wait (60s) for the outcome
SAP_ENABLE_TRANSPORTS=true vsp -s qassys transport status TR-EXAMPLE --job 12345678   # queued / pending / job_failed / unknown, read-only
SAP_ENABLE_TRANSPORTS=true vsp -s qassys transport buffer TR-EXAMPLE      # read-only view of the queue
SAP_ENABLE_TRANSPORTS=true vsp -s devsys transport download TR-EXAMPLE -o ./out   # copy out of DIR_TRANS; changes nothing, but refused under --read-only (data files can hold table contents)

MCP (expert mode only): system with upload_transport (cofile_path + datafile_path, or cofile_name/cofile_base64 + datafile_name/datafile_base64), and the read-only transport_status (transport, job) and transport_buffer (optional transport).

The upload answers as soon as the files are written and the background job that adds the request is released: status pending and the job's number. transport_status / vsp transport status then say queued only when the buffer file holds the request and the job is done, pending while it runs, job_failed when it ended without the request in the buffer, and unknown otherwise -- check STMS and the job in SM37 then. The job also pushes its outcome to the WebSocket that started the upload (AMC application ZVSP_TRANSPORT, channel /buffer, which vsp install zadt-vsp creates), so vsp transport upload learns it within a second or two instead of polling; the status call still decides, and without the AMC application the upload works the same, polling. An upload committed but never handed to a job (the session ends, or a new upload begins) has its files deleted again.

A request whose SID is the connected system's own (exported from this very system) is uploaded like any other: putting a system's own released request back into its queue -- after its files were lost, say -- is a legitimate use, and the import, if any, is still a human decision in STMS.

The rules, checked in vsp and again in ZADT_VSP's ZCL_VSP_TRANSPORT_SERVICE: both files, matching number and SID, the cofile's shape (a header and an export step from its SID), 50 MB together; the target is always the server's own system and client (a system, client or directory parameter is refused); a file that exists in DIR_TRANS is never overwritten, not even an empty one; a request already in the buffer is not added again; and the only tp command that can be sent is the literal ADDTOBUFFER, which a test over the ABAP source enforces. Refused under --read-only and --transport-read-only; needs --enable-transports; --allowed-transports applies to the request. On the system it needs ZADT_VSP (redeploy: vsp install zadt-vsp) and S_CTS_ADMI with EPS1 (files) and TADD (buffer). tp is started over synchronous RFC, which a ZADT_VSP (APC) session may not do, so the add runs as background job ZVSP_TRANSPORT_BUFFER under the caller's user (S_BTCH_JOB to release it); vsp waits for its result. The add is recorded in tp's user log (ULOG), the TMS alert log and the cofile (a < step line) -- not in TPSTAT, which has no row for ADDTOBUFFER. transport_buffer / vsp transport buffer read the buffer file DIR_TRANS/buffer/ directly (no tp, no job), so they stay available under --read-only. If the buffer add fails while the request is certainly not in the buffer, the two files this upload wrote are deleted again. Taking a request out of the queue again is done in STMS.

Whether a request has been imported, and how it went, is in TPALOG: MCP system with the read-only import_status (transport: one request, a comma-separated list or an array; optional since, YYYYMMDD[hhmmss]) lists the tp steps each request has in this server's own system, oldest first, with the worst return code. No steps means tp has not touched the request there, or, with since, not since that time: an earlier import is filtered out, not absent. Each step carries its client, step code, return code, time and target system (TARSYSTEM). Step times and since are UTC (TRTIME is a UTC time stamp). In the system the request was exported from, TPALOG also holds the export steps (E, e, f), and maxRc covers them too, so having steps there does not mean the request was imported. It reads TPALOG over classic RFC (RFC_READ_TABLE, with a WHERE clause vsp builds from the checked request numbers), so it needs the system's RFC settings, --enable-transports (or --allow-transportable-edits) and a request that --allowed-transports lets through, and it stays available under --read-only.

Import an abapGit zip into a package in one call, with the abapGit installed on the system: an offline repository for the package, abapGit's deserialize checks, deserialize, activation -- and back come the outcome, abapGit's errors and warnings, the TADIR rows created or changed and the repository key. git delete-objects undoes it item by item.

vsp -s devsys git import-zip ./demo.zip --package '$ZDEMO'               # waits up to --wait (5m) for the job
vsp -s devsys git import-zip ./demo.zip --package '$ZDEMO' --overwrite   # into its existing offline repository, overwriting
vsp -s devsys git import-status 12345678                                 # a job still running, read-only
vsp -s devsys git delete-objects --package '$ZDEMO' "PROG ZDEMO_REPORT" "CLAS ZCL_DEMO"
vsp -s devsys git delete-objects --package '$ZDEMO' --delete-repo "PROG ZDEMO_REPORT"   # and unregister its offline repository
vsp -s devsys git object-versions --package '$ZDEMO' "CLAS ZCL_DEMO" --sha256          # read-only: the versions to expect
vsp -s devsys git delete-objects --package '$ZDEMO' "CLAS ZCL_DEMO" \
    --expect "CLAS ZCL_DEMO sha256="                     # only while it is still that version

MCP: system with git_import_zip (file_path or zip_base64, package, repo_name, overwrite, transport, wait_seconds), the read-only git_import_status (job), git_delete_objects (package, objects, delete_repo, expect_repo, keep_order), and the read-only git_object_versions (package, objects, sha256).

Nothing that exists is overwritten without overwrite, and a package that already has a repository is refused without it. A package that exists without a repository is imported into without overwrite; its own package entry is left as it is. overwrite also needs deletes allowed (--disallowed-ops without D), since abapGit deletes and recreates an object whose type changed. Unmet requirements or APACK dependencies, an object of another package, a package move, potential data loss, an unsupported object type and table content refuse the import; a local object the zip does not have is never deleted. Before a byte is sent, vsp reads the zip's .abapgit.xml and folders and checks the target package and every package the zip maps to against --allowed-packages; ZADT_VSP checks again that every file maps to one of those packages. A transportable package needs --allow-transportable-edits and a transport (named, or chosen as for any write); a local one takes none, and only a local one is created by the import. Refused under --read-only.

git_delete_objects deletes exactly the listed TADIR items -- each only when the package's TADIR has it, each through the same gated delete as any other -- then the package itself if nothing and no subpackage is left and no abapGit repository is registered for it. Nothing outside the package is deleted, a package is never an item, and when an object cannot be deleted the repository and the package stay. The repository registered for the package (its row: URL, branch, settings) is kept unless delete_repo: true (--delete-repo) is given, and then it is unregistered only if it is offline and the package is empty after the deletes; ZADT_VSP checks both again. An online repository is never unregistered: delete_repo with one is refused before anything is deleted. A repository abapGit cannot open counts as online, and the package is never deleted while any repository is registered for it. Objects are deleted at their own ADT address (an include, a structure), looked up by name.

To delete only what is still the version you decided on, read the versions first (git_object_versions, vsp git object-versions --sha256) and pass them back: an object {"type", "name", "expect": {"sha256": ...}} (or "stamp"; with both, sha256 decides). vsp takes the object's ADT lock, reads its version again while it holds the lock, and deletes it only on a match; otherwise its status is changed, with what it is now (observed), and it is kept. A version that cannot be read never matches. Objects are checked and deleted one at a time: when one comes back changed (or failed), the other objects listed are still deleted; only the repository and the package are kept. There is no all-or-nothing mode yet.

Objects are deleted users before what they use: code (PROG, CLAS, INTF, FUGR, XSLT and any type not named here), then RAP (SRVB, SRVD, BDEF, DCLS/DDLX, DDLS), then search helps and lock objects (SHLP, ENQU), table types (TTYP), tables and structures (TABL), data elements (DTEL), domains (DOMA); within a type, in the order given. An append structure is not yet ordered before the table it extends (both are TABL): list it first. keep_order: true (--keep-order) deletes exactly in the order given. The result's order is every delete attempt in the order made; an object retried after a failure is listed twice. Each expectation is read right before its own delete, after the deletes ahead of it, while a sha256 read before the call is of the state before any of them -- which is why the order matters: deleting a data element first changes the serialisation, and so the sha256, of a table that uses it, and the table would come back changed.

The ADT lock is the workbench enqueue: a second ADT session -- even the same user's -- is refused while it is held (checked live: EU 510), and abapGit's import refuses an object with that lock entry. That editors outside ADT (SE38, SE24, SE11, SE51 for dynpros, SE41 for GUI status, SE63/SE61 for texts and documentation) take the same enqueue for every part they write is expected but has not been verified for each of them; anything that writes the tables directly, without the enqueue, is not held off by it. expect_repo: {"key", "name"} (--expect-repo-key, --expect-repo-name) unregisters the repository only when it is exactly that row; otherwise repoNote is kept: registered repository is .

Use sha256 when it matters. It is the SHA-256 (lower-case hex) of the UTF-8 text of the lines =, one per file of the object's abapGit serialisation in its original language only, sorted, joined by LF without a final LF -- so it covers everything abapGit serialises for the object. It sees only the active version: an object with an inactive version (a row of the inactive worklist DWINACTIV for it or a part of it, reported as inactive) is never a sha256 match, so unactivated work is not deleted unnoticed. Reading it serialises the object with abapGit, which only reads.

The stamp is cheaper and coarser: v2::::, the newest change date and time over the object's dated version rows (active and inactive), the number of those rows, and the first 16 hex digits of a SHA-256 over the rows of some tables that carry no date:

What the stamp does not see, so that a change there alone leaves it as it was: documentation (DOKHL/DOKTL) of every type; a program's GUI status and titles (EUDB, RSMPTEXTS) and a dynpro changed without being generated; a class's or interface's SOTR texts, sub-component texts (SEOSUBCOTX: parameter and exception descriptions), relations and friends (SEOMETAREL, SEOFRIENDS) and component properties its source does not carry; a table's field texts (DD03T), foreign keys (DD05S, DD08L) and search help field mapping (DD36M), unless the change also updated a dated row; and two changes within the second the stamp was read in. Other types have no stamp.

The stamp also moves where sha256 does not: on a translation in any language (it reads the text tables in every language; sha256 covers the original language only), and on a dynpro's regeneration (D020S's generation date moves without a change). Both give a changed where nothing sha256 covers changed -- the safe side. Inactive versions are looked up by name, whatever the object type, so an inactive DTEL ZFOO also marks DOMA ZFOO inactive -- the safe side too. A ZADT_VSP too old to report inactive makes a sha256 expectation failed ("ZADT_VSP too old"), never a match.

A zip is refused above 20 MB, 50,000 entries or 200 MB unpacked (its declared sizes, checked by vsp and again by ZADT_VSP before abapGit unpacks it), and with more than one .abapgit.xml at its root. If the import's commit gets no answer, the job may be running: vsp says so, and git_import_status or SM37 (job ZVSP_GIT_IMPORT) tells.

abapGit's deserialize commits with WAIT, which a ZADT_VSP (APC) session may not do (it dumps APC_ILLEGAL_STATEMENT), so the import runs as background job ZVSP_GIT_IMPORT under the caller's user; its outcome is pushed to the WebSocket that started it (AMC application ZVSP_GIT, channel /import) and kept a week for git_import_status. Needs ZADT_VSP with the git service, which vsp install zadt-vsp deploys where abapGit is installed (with the job program and the AMC application); without abapGit the rest of ZADT_VSP still runs.

vsp update fetches the latest release for this platform, compares it with the running version, verifies the download against the release's checksums.txt, and puts it in place of the running binary — the old one is renamed aside first, which is what Windows allows for a running executable. The release comes from the repository the binary was built for: these releases are github.com/oisee/vibing-steampunk, and a fork's own releases update from that fork; a local make build carries no stamp and uses the default. --repo owner/name points at a different repository for one run.

vsp update --check                                   # vsp 2.56.0, latest in oisee/vibing-steampunk is 2.57.0 (vsp-linux-amd64): update available
vsp update                                           # download, verify, replace
vsp update --version v2.55.0 --force                 # a particular release, newer or not
vsp update --repo myorg/vibing-steampunk --check     # a different fork's releases

Cluster tables, decoded — BALDAT, INDX, STXL over plain ADT

BALDAT is one of a family: INDX, STXL, and every table an EXPORT ... TO DATABASE writes to. The rows are ordinary — a key, a sequence number, a byte count and a RAW column — and ADT's data preview returns all of them. What nothing on the SAP side does for a remote caller is turn the RAW column back into data: it is an SAP-compressed data cluster, and only IMPORT reads it.

vsp cluster does it here. SAP's "LZH" turned out to be DEFLATE behind an eight-byte header and a two-bit prefix, so the standard library inflates it; "LZC" is compress(1) and is ~100 lines. The cluster itself carries a type descriptor for every exported object — kind, length and decimals of every field, nested for structures, a line type for a table inside a structure — so the values come back typed: packed numbers as decimals, time stamps with their microseconds, strings from their out-of-line segments, a table-typed component as its rows. What it does not carry is field names. --layout supplies them: a DDIC structure is read from DD03L, includes resolved, and laid over the descriptor field by field — type family, byte length and decimals checked at every leaf, so a structure that does not fit is refused with the field named rather than guessed at. Two layouts are built in: applog for BALDAT, and stxl for SAPscript text, which STXL gets by default.

vsp cluster decode snapshot.bin --json                 # an EXPORT TO DATA BUFFER, downloaded, decoded offline
vsp -s a4h cluster read INDX --where "relid = 'ZV'" --schema   # every object, every field typed
vsp -s a4h cluster read INDX --where "relid = 'ZD'" --layout ZDEMO_S_HEADER
vsp -s a4h cluster read INDX --where "relid = 'ZD'" --layout "HDR=ZDEMO_S_HEADER,ITEMS=ZDEMO_S_ITEM"
vsp -s a4h cluster read STXL --where "tdname = 'ZDEMO_TEXT'"   # the text, lines and formats
vsp -s a4h cluster read BALDAT --where "relid = 'AL' AND log_handle = '...'" --layout applog
vsp cluster decode baldat.txt --layout applog                  # from an SE16H download, no system

The offline form is the one for a system where SE16H is all you have: export BALHDR to find the log handles, export the matching BALDAT rows, decode them on your machine. On the MCP side it is analyze type=cluster_read, and application_log takes messages: true.

Verified against clusters written by a 7.58 kernel: every elementary type, compressed and not; DDIC-typed structures and tables; tables inside structures, tables inside table rows, sorted and hashed tables, tables of strings, bare strings — and against BALDAT from a 7.5x system. Version 5 clusters — what a pre-Unicode kernel wrote, and what old rows still are after a Unicode conversion — are read too, from EUFUNC and AQLDB. The same reader opens VARI (report variants, one object per parameter), LTDX (ALV layouts), MONI (workload statistics), SOC3 (SAPoffice documents), EUDB and STXL on sight, and EUFUNC gives the Function Builder's saved test data: every parameter by name, the result, the runtime, the return code.

vsp cluster decompress is the compression alone, for streams that are not clusters — REPOSRC's source column, dumped to a file by a few lines of ABAP, decompresses with --skip 1 --text.

Checked on 7.50, 7.57 and 7.58. 7.50 serves the dump feed but not the detail resource, so there is no call stack to read there — the correlation drops that rung and still ranks on the rest.

The MIME repository, byte-exact — SMW0 over plain ADT

Anything uploaded through SMW0 — a logo, a sound, a font, a PDF, a Z-machine game a websocket handler loads at runtime — is reachable, and comes back byte for byte.

It is not a column you can select. SMW0 writes the file into WWWDATA as an INDX-style data cluster: LZH-compressed, split over as many rows as it takes, and inside the cluster a table of fixed 255-byte lines. The last line is padded with zeroes, so the cluster alone cannot say where the file ends. The true length is the filesize parameter in WWWPARAMS, and truncating to it is the whole difference between a file and a nearly-right file.

vsp -s a4h w3mi list                                  # every MIME object with size and type
vsp -s a4h w3mi list 'ZDEMO%'                         # SQL LIKE on the object id
vsp -s a4h w3mi get ZDEMO_LOGO.PNG --out logo.png
vsp -s a4h w3mi get ZDEMO_LOGO.PNG --abapgit-dir src/ # the abapGit pair, ready to commit

Both halves are ordinary table reads, so nothing goes on the server: no abapGit, no RFC, no ZADT_VSP. --abapgit-dir writes the pair abapGit expects — .w3mi.data. plus .w3mi.xml, with the object id escaped the way abapGit escapes it (ZORK-MINI.Z3 → zork-mini%2ez3).

The filename parameter is deliberately not written into that XML, and a test enforces it: it records the path the file was uploaded from — a user name, a host, a directory layout — and these files are meant to be committable.

Where a wrong answer would look like a right one, it refuses instead of guessing. A non-zero byte past filesize means filesize and the cluster disagree; a cluster shorter than filesize means the object is truncated on the system. Both say so rather than hand back a plausible file.

Verified on arithmetic that can fail. A 52216-byte game came out of 205 lines of 255 = 52275, truncated to filesize, and the 59 discarded bytes were all zero — then the file checked itself: a Z-machine v3 header declares its own length at 0x1A and its checksum at 0x1C, and both matched what came out. Two further extractions by different routes produced the identical md5. A single bad byte anywhere would have broken the checksum.

What really ran: vsp trace

A static call graph is a hypothesis. ABAP resolves CALL FUNCTION lv_name, PERFORM (f), CALL METHOD (m) and every RFC destination at runtime, so only a measurement knows what a program actually called.

vsp trace run ZADT_DEBUG_LOOP --call     # arm a SAT trace, fire it, print the tree
vsp trace list                           # traces this system holds
vsp trace tree  --json               # one JSON object per statement

SAT does the measuring and vsp reads the result, so it costs almost nothing and runs against real workloads. The tree it produced for a two-statement module already contains an edge no extraction would find: PERFORM (ext) %_BEFORE_COMMIT → SAPMSSY0.

And the expensive half, for when the tree is not enough and you want the values:

vsp trace unit ZADT_DEBUG_LOOP --line 9 --call --values

anchors a breakpoint, waits for somebody to run the unit, then steps over its statements — never descending into what it calls — and writes one JSON object per stop. Against A4H that is the unit's whole data flow in seven records: line 9 with LV_LOW empty, line 14 with LV_LOW=44 once the SELECT had landed, line 15 with LV_COUNTER=45, then an exit marker. Values are redacted to «type:length» unless --values is given, because a capture at a code boundary is business data by construction.

It is a deliberate mode, and the numbers say why. A stop needs the step, the stack and the variables — four round trips, since variables take two. Measured on A4H over a LAN in August 2026 that is about 45ms a stop, some 1300 a minute. /sap/bc/adt/debugger/batch takes them as one multipart document and works through the tunnel: 14ms, some 4300 stops a minute on the same system. The harness is pkg/saprfc/step_cost_test.go, behind the integration tag; the numbers are one machine on one network, not a specification. Two other measured limits shape it — SAP allows 30 external breakpoints per user, and stepping past the end of a unit whose caller is standard code ends the debuggee rather than stopping, which is why a recording ends with an explicit exit record instead of an error.

The write-up, with everything that had to be learned on the way: reports/debugger-over-rfc.md.

Classic RFC — Call Any Function Module, No SAP SDK

vsp now speaks classic RFC next to ADT, through the pure-Go, SDK-free open-rfc-go client — no NW RFC SDK, no native library, no cgo. Same system, second protocol: ADT reads and writes code, RFC calls the business logic.

vsp rfc info                                     # RFC_SYSTEM_INFO (sysid, release, host)
vsp rfc search 'BAPI_USER_*'                     # find RFC-enabled function modules
vsp rfc describe STFC_STRUCTURE                  # FM interface as an MCP-tool JSON Schema
vsp rfc call Z_DOUBLE '{"N":21}'                 # call any FM with JSON parameters
vsp rfc read-table T000 --fields MANDT,MTEXT     # RFC_READ_TABLE

The destination is derived from the system you already configured: host from the ADT URL, system number from its port, gateway port 3300 + sysnr. Override per system in .vsp.json (rfc_host, rfc_sysnr, rfc_port) or per command (--rfc-host, --sysnr, --port). RFC logon uses rfc_user/rfc_password, else SAP_USER/ SAP_PASSWORD, else the system's own credentials. An MCP server takes the RFC settings of its own system (the one named by -s/SAP_SYSTEM, else the entry whose URL and client match its own; a named entry whose URL or client is not the server's is refused), and logs on with that entry's rfc_user/rfc_password, else its own credentials. SAP_USER/SAP_PASSWORD are used only by a server without credentials of its own (cookie or SSO logon), and only when SAP_URL and SAP_CLIENT name its system.

In MCP it is one more action on the single SAP tool — the tool space stays as small as it was:

SAP(action="rfc", params={"op":"info"})
SAP(action="rfc", target="Z_DOUBLE", params={"op":"call","args":{"N":21}})
SAP(action="rfc", target="STFC_CONNECTION")      # describe (default with a target)
SAP(action="rfc", target="T000", params={"op":"read_table","fields":["MANDT"],"top":5})
SAP(action="rfc", target="ZREPORT", params={"op":"run","variant":"DEFAULT"})  # background job: spool + job log

Types are handled end to end — scalars (incl. STRING/XSTRING, DATE/TIME, packed DEC/TIMESTAMP, FLOAT), flat and deep structures and tables (xRFC) — and both the classic and fast serializations on the wire.

And RFC does things ADT cannot:

vsp rfc probe                                    # what is this system, and what may this user do here
vsp rfc export ZPACKAGE -o pkg.zip               # abapGit ZIP in one call
vsp rfc run RSPARAM --wait 60 --spool            # run a report as a background job, read its spool
vsp rfc adt GET /sap/bc/adt/discovery            # ADT REST tunnelled through RFC, for when ICF is closed
vsp rfc debuggees                                # who is parked in the debugger, and where

And the debugger is only the hard case — potentially all of ADT rides RFC

SADT_REST_RFC_ENDPOINT takes a whole HTTP request, so any ADT resource is reachable over the gateway port: source read and write, activation, ATC, unit tests, transports, search, refactoring — the surface vsp already speaks, on a system where ICF is closed, HTTPS terminates somewhere inconvenient, or CSRF and cookies are a fight:

vsp rfc adt GET /sap/bc/adt/discovery                 # 200, 299 KB atomsvc
vsp rfc adt GET /sap/bc/adt/programs/programs/RSUSR000/source/main
vsp rfc adt POST /sap/bc/adt/atc/runs Content-Type=application/xml --body run.xml

Read paths are proven (discovery, program source with ETag/Last-Modified, a missing object answering ADT's own 404 document). The write sequence has been demonstrated by hand on A4H and is not yet covered by a test, so it is shown here as a worked example rather than as a guarantee:

POST …/oo/classes/zcl_x?_action=LOCK&accessMode=MODIFY   → 200, a lock handle
PUT  …/oo/classes/zcl_x/source/main?lockHandle=…         → 200   ← a separate request
POST …/oo/classes/zcl_x?_action=UNLOCK&lockHandle=…      → 200
POST /sap/bc/adt/activation?method=activate              → activated

An ADT lock is bound to an ABAP session — precisely what a short-lived HTTP client cannot hold, which is why LOCK in one call and UPDATE_SOURCE in the next fails with InvalidLockHandle, and why EditSource has to do everything inside a single call. A pinned RFC conversation holds exactly that session, so the handle is still valid on the next request.

And the class used for the test is one the HTTP client could not even lock: it answers MODIFICATION_SUPPORT=NoModification, which is SAP saying "no modification assistant needed here", not "read-only". So editing over RFC is not merely equivalent to editing over HTTP — on that system it is strictly more capable. (Order matters: activate after unlock, or the object's own ENQUEUE answers 403 … is currently editing ….)

Package Analysis Suite

Five analysis commands that answer real questions about your ABAP packages:

vsp health --package '$ZDEV'                    # tests + ATC + boundaries + staleness
vsp health --package '$ZDEV' --report html      # full HTML report with details
vsp slim '$ZDEV' --level methods                # dead code detection (method-level)
vsp api-surface '$ZDEV' --include-subpackages   # Clean Core: which standard APIs do you use?
vsp boundaries '$ZDEV'                          # directional boundary crossing analysis
vsp boundaries '$ZDEV' --format mermaid         # visual graph with package subgraphs

Transport & Change History

vsp changelog '$ZDEV' --since 20260101          # what changed in this package?
vsp changes '$ZDEV' --attribute SAPTEST         # group transports by CR attribute (E070A)

Directional Boundary Crossings

Not just "crossed" or "not crossed" — which direction the dependency flows:

Export to 7 formats: text, json, md, mermaid, html, dot (Graphviz), plantuml, graphml (Gephi/yEd).

Side Effect & LUW Analysis

vsp -s dev effects ZCL_DEMO_ORDER      # from SAP
vsp effects --file ./local.abap        # no system needed

  LUW          unsafe
               both commits and registers deferred work — part of what it queues
               is committed by each
  reads        ZDEMO_ORDERS
  writes       ZDEMO_ORDERS
  effects      COMMIT WORK, IN UPDATE TASK

Also SAP(action="analyze", params={"type": "effects", ...}).

The interesting effects in ABAP are not database writes but LUW effects: a unit calling IN UPDATE TASK has not written anything yet, and whoever calls COMMIT WORK higher up triggers everything it queued. That is invisible coupling, and nothing in SAP's toolchain reports it.

The analysis is local — it reads the unit's own source and nothing it calls — and every answer says so.

The parser detects transactional patterns in ABAP source:

LUW classification: safe / participant / owner / unsafe.

Health Reports

Full health reports with test details, ATC findings, and boundary crossings:

vsp health --package '$ZDEV' --details          # text with all details
vsp health --package '$ZDEV' --report md        # → _ZDEV.md
vsp health --package '$ZDEV' --report html      # → _ZDEV.html
vsp health --package '$ZDEV' --report my.html   # → my.html

Tests discover embedded local test classes across the full package hierarchy — the same as Eclipse Ctrl+Shift+F10.

More

• vsp graph co-change CLAS ZCL_FOO for transport-based co-change analysis
• vsp graph where-used-config ZKEKEKE for heuristic TVARVC usage discovery
• .vsp.json transport_attribute for per-system CR correlation config
• Analysis & Refactoring Guide for what these commands do
• Graph Guide for examples, data sources, and current limits

0x1D3 Stars!

Read the latest: The frontier went down a layer — since April: a rogue DIAG server a real SAP GUI draws from, the family's first SAP-LZH writer accepted by a live kernel, and the dump-RCA loop closing on itself. 467 stars, and still only 5% explored.

Earlier: Still Only 5% · VSP Is Only 5% Explored · Agentic ABAP at 100 Stars

What's New

The headline changes are in the "New in the last three releases" callout at the top of this README; the full version history is in CHANGELOG.md. Latest release: v2.61.0 — snc and traces.

v2.61.0 — new since v2.60.0

Reach SNC-only systems from one vsp.exe, and read ABAP traces as they really are.

New: SNC single sign-on through SAP's sapnwrfc.dll (Windows). A system with an snc block in ~/.vsp.json logs on with Kerberos through the SAP NW RFC SDK and carries ADT over RFC, with no password and no browser. The block names the SAP Logon entry, system, client, user and production. vsp.exe runs itself as the helper (vsp snc-serve) and loads the SDK only in a guarded worker:

• tracing is off and the worker's directory refuses files;
• DLLs are searched only beside the SDK and in System32;
• the logon is never retried;
• the system, client and user are checked after logon.

The channel is read-only. On "production": true it forwards GETs only; elsewhere it forwards bounded data preview SELECTs too. In .mcp.json it is just ["-s", "dev"]. From WSL, a Linux vsp uses the Windows vsp.exe as its transport_cmd. The SDK itself is SAP's: download it from the SAP Software Center. See SNC single sign-on through sapnwrfc.dll.

New: transport command. transport_cmd in ~/.vsp.json (or --transport-cmd, SAP_TRANSPORT_CMD) carries every ADT request over a helper process's stdin/stdout, and the helper does its own sign-on (#373). -s NAME gives the MCP server its logon from such a system. See Transport command.

Fixed:

• ABAP traces read as they are (#376).
  • get_trace returned empty hit-list entries on 7.58. It now parses the real format: event, program, line, calls, own and total time.
  • It sorts by own time and returns the top 50 (top, sort_by). It also reads dbAccesses and the call tree, and returns raw XML on request.
  • list_traces shows state, aggregation, size and runtime, newest first.
  • A trace cut off at its size limit now says so instead of returning a bare 416.

Behaviour changes:

• A transport_cmd program must be an absolute path. The helper runs in its own directory and starts from vsp's environment as it was before ./.env was loaded, so a project's files and .env cannot reach it.
• The snc block requires "production".

v2.60.0 — new since v2.59.1

Debug from your editor, pin where vsp may work, read less to know more. v2.59.x continues as an LTS line on release/2.59 (fixes only).

New: vsp dap, a Debug Adapter Protocol server. It lets you debug ABAP from VS Code, nvim-dap or JetBrains on a real system, with no Z code. See Debug from your editor (DAP).

New: read summary. SAP(action="read", ..., params={"summary": true}) (vsp source read ... --summary) returns the lines, bytes and sha256 of the source instead of the source. params={"if_none_match": ""} (--if-none-match) answers "unchanged: source sha256 …" while the source still has that digest. Only the object's own source is compared, not the dependency context. A read with include_hash now carries the same sha256. The digest is over the exact text, not normalised. See Read Summary.

Fixed:

• vsp dap releases everything it took. Every exit path (disconnect, end of stream, a signal, a failed step or attach) clears the breakpoints, releases the debuggee and stops the listener. A disconnect during a listen no longer waits behind it: measured on a real system, 58 s → 0.1 s (#346).
• A failed BADI_IMPL leaves no empty ENHO (#349, ported from #336). The shared cleanup after a failed create now also releases the lock it took, and a container whose transport request can't be established is kept, with the manual step named, rather than deleted past --allowed-transports.
• The leak scan can't be blinded. Control bytes in a commit message, a file name or a foreign message encoding no longer hide a value from it, and it never prints a scanned path or value in its own log (#347).

Moved out: the ABAP transpilers (vsp compile) now live in ABAPiti.

New: --expect SID[.CLIENT][/USER] (or SAP_EXPECT, or "expect" on a .vsp.json system) pins where vsp may work, e.g. --expect A4H.001/DEVELOPER. A configured user that differs is refused at startup, before any logon. On the first request, vsp asks the system for its SID, client and user and refuses everything when they differ. SAP() shows pinned: A4H.001/DEVELOPER ✓. Without a pin, nothing changes and no extra request is sent. The server's startup log and vsp config show now say where the logon came from.

Platforms: six binaries: linux-amd64, linux-arm64, darwin-amd64, darwin-arm64, windows-amd64 and windows-arm64. vsp-linux-386, vsp-linux-arm and vsp-windows-386 are no longer built. On those platforms, install from source instead: go install github.com/oisee/vibing-steampunk/cmd/vsp@latest (vsp update from v2.59.x only reports that the release has no asset for the platform and leaves the installed binary alone; from v2.60.0 on it says why and gives this command).

v2.59.1 — new since v2.59.0

The first release built, checked and published by CI on the tag push (.github/workflows/release.yml), not by hand.

Release assets fixed

• vsp-linux-amd64 is static again. v2.59.0's needed glibc 2.34 or later. Every binary is now built with CGO_ENABLED=0.
• LICENSE and NOTICE ship with the binaries. Apache-2.0 components are embedded.
• The build info names the release commit. CI refuses a binary whose Go VCS stamp is not the tag's commit or comes from a modified tree. It runs --version on Linux, macOS and Windows (x64 and ARM), and publishes only after downloading the draft back and comparing it byte for byte (#329).

New

• Has a transport been imported here, and how did it go? MCP system import_status reads a request's tp steps from TPALOG, read-only (#332, ported from #297).
• Activation failures say why. vsp install, copy, source write and source edit print the activation messages: object, line and text, capped at 20 (#333).
• Long writes take the call timeout. WriteSource, EditSource and the activations honour --call-timeout / params.timeout, so a large program is no longer cut at 60 s. A lock taken before the time ran out is still released. If vsp cannot confirm the release, it says the lock may still be held (#333).

Fixed

• Deleting or updating with your own lock handle on SAP_BASIS 816. The package check now runs inside that lock's session, so the write no longer comes back 423 (#331, ported from #292).
• No false "package does not exist". The check before a create read "404" anywhere in an error, including a port number in its URL, so a timeout could be reported as a missing package (#338).

Removed

• Three MCP tools that did nothing useful. InstallAbapGit deployed nothing but reported success, InstallDummyTest was a test tool, and WriteDataElementLabels always refused. abapGit's standalone edition still installs with vsp install abapgit --edition standalone (#334, #277).

Coming in the next release: fewer platforms. vsp-linux-386, vsp-linux-arm and vsp-windows-386 will no longer be built. Together they were about 6% of downloads. The remaining six are linux, macOS and Windows, each on amd64 and arm64.

v2.59.0 — new since v2.58.0

Transports and change control

• Upload a released transport and add it to the import queue — never import. vsp transport upload / system upload_transport writes the cofile and data file into DIR_TRANS and adds the request to the buffer; the import itself stays a human step in STMS (#296). Also: transport status, transport buffer and transport download.
• A transport of copies of a request, as SE01 builds one (#247); entries added to a request and taken out, as SE09 does (#262); requests filed under a CTS project (#246); a refused release is reported, not swallowed (#248).

abapGit offline zip import (#301). vsp git import-zip / system git_import_zip imports an abapGit zip with the abapGit already on the system, as a background job; git import-status reports on it and git delete-objects removes exactly what it brought. Needs ZADT_VSP and abapGit. Every package the zip maps to must pass --allowed-packages. git delete-objects deletes only what is still the version you saw: per-object expect (sha256, or a coarser stamp), checked under the ADT lock, expect_repo for the repository row, and the read-only git_object_versions (vsp git object-versions) to read them (#320).

Code, run and checked

• ExecuteABAP answers JSON: result_text is the value in full, RETURN_VALUE( x ) hands back any number of values (structures and tables as JSON), and a run that did not finish says where in your code (#298).
• ABAP Unit results as JSON with counts; a class ABAP Unit refused to run is not a pass; only_failures for a short answer (#298).
• Check a snippet without running it: vsp check-abap / analyze check_abap, SAP's own syntax check, findings in the snippet's lines (#300).
• Long calls take a timeout (seconds), and --call-timeout / SAP_CALL_TIMEOUT sets the server's default (#299).
• Run a report as a background job from the SAP tool (#261).

Read and find

• Exact-name search: params.exact / vsp search --exact (#299).
• A package's inventory in one call: read DEVC $PKG with params.inventory — objects with author and date, subpackages, and its abapGit repository (#299).
• An IDoc as WE02 shows it (#268).
• vsp query accepts the common ANSI spellings and explains what SAP refuses (#267).

Create

• Domains and data elements (#273), structures and append structures from DDL (#272), message classes with messages in the language asked (#270), and enhancement implementations — source plug-ins and BAdI implementations (#263).

Safety and quality

• Delete only the version you saw: git_delete_objects takes an expected stamp or sha256 per object, checked under the object's lock right before its DELETE; a changed object is kept and reported (#320). Dependent objects are deleted before what they use (#323), and git_object_versions reads the versions first.
• Typed abapGit files take their name from the file name, never the content, so a TOP include can no longer overwrite its main program (#305, #312).
• Table reads with caller SQL are refused under --block-free-sql (#310); every ZADT_VSP WebSocket authenticates the way its ADT client does (#306).
• Graph and health: program callers and their main programs (#309), one data source for CLI and MCP (#322), health reads classes and function groups and names what it could not read (#325).
• A leak scan blocks commits that carry system identifiers (CI and an opt-in pre-push hook); correctness lint blocks new code; the PR report shows complexity and token drift; an advisory integration run against the OSD SAP emulator on every PR (#311, #321, #324, #326).

Fixed, among others: concurrent callers of one client no longer break each other's locks (#251); a cookie-jar race (#229); credentials and the CSRF token stay on the SAP host across redirects (#257); namespaced objects and function groups (#233, #274, #282); activation of a group with its inactive parts (#271); a failed transport download is an error (#302).

Behaviour changes you may notice:

• execute_abap (MCP) answers JSON instead of text.
• vsp execute exits non-zero when the code did not finish, never ran, or left its temporary program behind; vsp test exits non-zero when a test class was not run.
• vsp update follows the repository the binary was released from (#259).
• git_delete_objects refuses an object given as a map with a key other than type, name and expect (a typo such as expected used to be ignored) (#320).

v2.59.0 — behaviour changes since v2.58.0

--read-only now also refuses, each before anything reaches SAP:

• transport writes (create, release, delete, merge, move, entry add/remove), even with --enable-transports;
• gCTS create, delete, clone, pull, commit and switch-branch;
• code execution: SAP(action="rfc") call, CallRFC (debug CALL_RFC), RunReport / RunReportAsync, and unit test and code coverage runs (RunUnitTests, GetCodeCoverage) that include dangerous or critical tests (include_dangerous). Ordinary runs still work;
• object and system changes: SetTextElements, MoveObject (edit MOVE, debug MOVE), publishing and unpublishing service bindings, SetPrettyPrinterSettings, and every lock except a READ lock (LockObject, edit LOCK);
• debugger variable writes through the ADT client (DebuggerSetVariableValue).

The CLI honours read_only in .vsp.json and SAP_READ_ONLY for vsp rfc call, rfc run, rfc adt with a method other than GET/HEAD/OPTIONS, vsp trace run --call, vsp trace unit --call, the Run button of vsp debug ui, run and call in the vsp debug REPL, eset and writing adt requests in the vsp rfc debug / vsp adt debug REPLs, and the vsp lua bindings that overwrite variables (setVariable, injectCheckpoint, forceReplay, replayFromStep).

--block-free-sql (and block_free_sql / SAP_BLOCK_FREE_SQL on the CLI) refuses rfc read_table / vsp rfc read-table with a caller's WHERE. Reads without one, and search, are unchanged.

RFC goes only to the server's own system. When -s / SAP_SYSTEM names a .vsp.json entry whose url/client differ from SAP_URL/SAP_CLIENT, the server warns at startup and refuses RFC use. An entry without a url (gateway only) still applies. A per-call host, sysnr or port on SAP(action="rfc") that differs from the server's own gateway is refused, so the configured RFC credentials never go to a caller-chosen destination.

Known gaps (not gated by --read-only yet): setting and deleting breakpoints, debugger stepping, starting an AMDP debug session, arming and removing traces (vsp trace run without --call, vsp trace rm), and the per-call RFC user override, which can still try other users' logons with the configured password and so risks locking an account. The name mask of rfc search is not escaped. vsp rfc adt POST is checked as a workflow operation (W), while vsp adt request checks the same kind of request as an update (U). Both are refused under read-only, but they use different operation letters.

Build and transport: go.mod pins toolchain go1.26.8. mcp-go v1.1.0 answers 403 to a request from a loopback address that carries a non-loopback Host header (DNS-rebinding protection), so a reverse proxy on the same host must rewrite Host to reach vsp over HTTP.

Hyperfocused Mode — 1 Tool to Rule Them All (Recommended)

Recommended for most setups. Single SAP(action, target, params) tool covers most of what the 148 individual tools do — gCTS, revision history and i18n still need --mode expert. The same tool is now registered in focused and expert too, so an agent in either can reach the analyze surface. Minimal token overhead, maximum capability.

SAP(action="read",   target="CLAS ZCL_TRAVEL")
SAP(action="edit",   target="CLAS ZCL_TRAVEL", params={"source": "..."})
SAP(action="create", target="DEVC", params={"name": "$ZOZIK", "description": "New pkg"})
SAP(action="help",   target="debug")

All safety controls (--read-only, --allowed-ops, --allowed-packages) work identically — the universal tool routes through the same handler → ADT client → checkSafety() chain.

Thanks to Filipp Gnilyak for the hyperfocused mode concept.

Context Compression — Built-in ABAP Understanding

GetSource auto-appends a compressed dependency prologue — public API signatures of every referenced class, interface, and FM. One MCP call = source + full surrounding context.

How it works:

graph LR
    A["GetSource
ZCL_TRAVEL"] --> B["10 regex patterns
scan source"]
    B --> C["TYPE REF TO
NEW · => · ~
INHERITING FROM
INTERFACES
CALL FUNCTION
CAST · RAISING"]
    C --> D["Fetch deps
5 parallel"]
    D --> E["Extract contract
PUBLIC SECTION only"]
    E --> F["Source +
Compressed Prologue"]

Compression by object type:

Ratios below are observed on real objects, not computed by a test — treat them as orders of magnitude. The 1x for interfaces is structural: an interface is already its own contract, so nothing is stripped.

Real-world example — ZCL_ABAPGIT_ADT_LINK (abapGit codebase):

• 8 dependencies detected → 8 resolved, 0 failed
• Dependencies include: ZIF_ABAPGIT_DEFINITIONS (massive interface), ZCX_ABAPGIT_EXCEPTION, CL_WB_OBJECT (14 methods), IF_ADT_URI_MAPPER (8 methods), etc.
• All compressed to public signatures only — no implementation bodies, no private sections

Method-Level Surgery — Read and Edit Individual Methods

Why pull an entire 1000-line class when you only need one 30-line method?

# Read just the FACTORIAL method — not the whole class
SAP(action="read", target="CLAS ZCL_CALCULATOR", params={"method": "FACTORIAL"})

# Edit just that method — vsp handles the rest
SAP(action="edit", target="CLAS ZCL_CALCULATOR", params={
  "method": "FACTORIAL",
  "source": "  METHOD factorial.\n    ...\n  ENDMETHOD."
})

What happens under the hood on edit:

sequenceDiagram
    participant LLM as AI Agent
    participant VSP as vsp
    participant SAP as SAP System

    LLM->>VSP: SAP(edit, CLAS ZCL_FOO, method=BAR, source=...)
    VSP->>SAP: GetClassMethods() → find BAR boundaries
    VSP->>SAP: GetClassSource() → full class
    Note over VSP: Replace lines 42-58
with new METHOD block
    VSP->>SAP: SyntaxCheck(full reconstructed source)
    VSP->>SAP: Lock → UpdateSource → Unlock → Activate
    VSP->>LLM: ✓ Method BAR updated, class activated

The AI only sends/receives the method block (~30 lines). vsp fetches the full class internally, splices in the new method at the right line range, validates, and pushes back. 95% token reduction vs full-class round-trips.

Context compression scopes to the method too — when reading a single method, dependency analysis runs on that method's code only, so the prologue contains exactly the types and interfaces relevant to the method you're working on, not the entire class's dependency tree.

Built-in ABAP parser based on abaplint by Lars Hvam — the same parser that powers abaplint's 392 ABAP statement types.

Read Summary — Is This the Version I Already Have?

A read can return what the source is instead of the source itself:

SAP(action="read", target="CLAS ZCL_CALCULATOR", params={"summary": true})
→ {"objectType": "CLAS", "name": "ZCL_CALCULATOR",
   "uri": "/sap/bc/adt/oo/classes/ZCL_CALCULATOR/source/main",
   "lines": 412, "bytes": 15873, "sha256": "3f0a…", "sourceHash": "sha256:9c1e…"}

# Later: only pay for the body if it changed
SAP(action="read", target="CLAS ZCL_CALCULATOR", params={"if_none_match": "3f0a…"})
→ unchanged: source sha256 3f0a… (CLAS ZCL_CALCULATOR, 412 lines, 15873 bytes); the source was not returned; dependency context not compared: read without if_none_match to refresh it

• sha256 is the lower-case hex SHA-256 of the exact text a read returns, not normalised: CRLF stays CRLF and a final newline stays. sha256sum over the text you received gives the same value.
• sourceHash is the normalised hash (CRLF→LF, trailing newlines dropped) for expected_source_hash on a guarded write. It is left out where WriteSource refuses one (a method-level read, a FUNC, types it does not write as source); sourceHashNote then says why.
• uri is the ADT source that actually served the text. When that is not the one asked for, requested names the original: a PROG that ADT knows only as an include is read from /programs/includes, and an ENHO names whichever of its endpoints answered.
• Never from the response cache. With VSP_CACHE=true (or cache: true for a system), a plain read can be answered from the cache for up to its TTL. summary and if_none_match always read SAP, so "unchanged" means unchanged now, not unchanged since the cache entry was made. The fresh answer refreshes the cache entry.
• if_none_match compares the object's own source only. The dependency context a default read appends is not compared, so a changed dependency still answers "unchanged", and the answer says so. Read without if_none_match to refresh the context. Pulling the context into the comparison would cost a round trip per dependency, which defeats the point.
• Neither equals git_delete_objects' expect sha256: that one is computed on SAP over the object's whole abapGit serialisation (one = line per file, XML included), so it is never a single source's digest.
• Both are the same single read as a normal one: no extra SAP round trip, and no dependency context (which costs one per dependency).
• With if_none_match and a different digest you get the normal read, body and all. summary and if_none_match together report "unchanged": true|false.
• version and last-changed author/date are not reported: a plain source GET does not say which version it served nor who changed it, and finding out would cost another round trip.
• CLI: vsp source read CLAS ZCL_CALCULATOR --summary, --if-none-match .

Token-saving tip: make the first full read with params={"include_hash": true, "include_context": false}: it returns the source together with its sha256. Keep that digest, and before re-reading the object ask with if_none_match: an unchanged 400-line class then costs one line instead of thousands of tokens.

Native Go ABAP Lexer — abaplint in Go

The abaplint lexer has been mechanically ported from TypeScript to native Go (pkg/abaplint). This is the same lexer that powers abaplint — 48 token types, all 6 lexer modes (normal, string, backtick, template, comment, pragma), with full whitespace-context encoding.

Verified via oracle-based differential testing against the real TypeScript abaplint:

=== DIFFERENTIAL KPI ===
Files:   29/29 passed (100.0%)
Tokens:  22,612 total
  Full match:  22,612 (100.0%)  — str + type + row + col
  Str match:   22,612 (100.0%)
  Type match:  22,612 (100.0%)
  Pos match:   22,612 (100.0%)

Zero dependencies, zero FFI. Pure Go, ~3.5M tokens/sec, ready for lint rules in Phase 2.

ABAP LSP — Real-Time Diagnostics

vsp lsp --stdio gives Claude Code (and other editors) automatic error detection and navigation for ABAP files. No explicit tool calls — the LSP pushes diagnostics as you type, debounced, and compressed dependency context on file open.

See LSP setup for configuration.

ABAP Transpilers — Moved to ABAPiti

The WASM/TypeScript/LLVM-to-ABAP transpilers (formerly vsp compile) now live in their own repo, ABAPiti, with their history.

Full CLI Toolchain — SAP from the Terminal

35+ commands. No SAP GUI, no Eclipse, no IDE. Most work with standard ADT; lint/parse work fully offline.

# Package analysis
vsp health --package '$ZDEV'                     # tests + ATC + boundaries + staleness
vsp health --package '$ZDEV' --report html       # full HTML report
vsp slim '$ZDEV' --level methods                 # dead code detection
vsp api-surface '$ZDEV' --include-subpackages    # Clean Core API inventory
vsp boundaries '$ZDEV' --format mermaid          # boundary crossings (visual)
vsp boundaries '$ZDEV' --report dot              # Graphviz export
vsp changelog '$ZDEV' --since 20260101           # transport history
vsp changes '$ZDEV' --attribute SAPTEST          # CR-level grouping

# Graph & dependencies
vsp graph CLAS ZCL_FOO --direction callers       # who uses this class?
vsp graph co-change CLAS ZCL_FOO                 # transport-based co-change
vsp graph where-used-config ZKEKEKE              # TVARVC readers (heuristic)

# Source & editing
vsp source CLAS ZCL_MY_CLASS                     # read source
vsp source CLAS ZCL_MY_CLASS --method GET_DATA   # read single method
vsp context CLAS ZCL_FOO --depth 2               # source + dependency contracts
vsp analyze ZCL_MY_CLASS                         # 13 lint rules (offline)

# Getting connected — before there is any config
vsp detect sap.example.com                       # which port serves ADT, and the config to use
vsp detect A4H --all                             # exhaustive sweep, by system id from SAP Logon
vsp landscape list --probe                       # every system SAP Logon knows, and which answer
vsp landscape import A4H --client 100 --write    # turn one into a .vsp.json entry
vsp -s dev compat                                # what this system supports, and how to route it
vsp -s dev compat --against prod                 # what two releases disagree about

# Classic RFC (no SAP SDK)
vsp rfc info                                     # RFC system info
vsp rfc call Z_DOUBLE '{"N":21}'                 # call any function module
vsp rfc describe BAPI_USER_GET_DETAIL            # FM interface as JSON Schema

# Debugging and tracing (nothing installed on the server)
vsp rfc debug                                    # debug REPL on a pinned RFC session
vsp adt debug                                    # the same REPL over stateful HTTPS
vsp dap                                          # the debugger for editors (Debug Adapter Protocol)
vsp trace run ZFOO --call                        # SAT trace: the measured call tree
vsp trace unit ZFOO --line 12 --values           # record a unit, statement by statement

# MIME repository (SMW0) — binary objects, byte-exact
vsp w3mi list 'ZDEMO%'
vsp w3mi get ZDEMO_LOGO.PNG --abapgit-dir src/

# Tables & search
vsp query T000 --top 5                           # query any table
vsp search "ZCL_*" --type CLAS --max 50          # object search
vsp grep "SELECT.*mara" --package '$TMP'         # source code search

# Testing & quality
vsp test --package '$ZDEV'                       # run unit tests
vsp atc CLAS ZCL_MY_CLASS                        # ATC code check

# Deployment & tooling
vsp deploy zcl_test.clas.abap '$TMP'             # deploy file to SAP
vsp export '$ZORK' '$ZLLM' -o packages.zip       # export abapGit ZIP
vsp install abapgit                              # install abapGit on SAP
vsp install zadt-vsp                             # install ZADT_VSP handler

# Offline tools
vsp lint --file myclass.clas.abap                # offline ABAP linter
vsp parse --stdin --format json < source.abap    # ABAP parser

See CLI Guide for the complete reference with feature requirements matrix.

Other Highlights

• Lua Scripting Engine: vsp lua — interactive REPL + scripts with 50+ SAP bindings. Query tables, lint code, parse ABAP, debug with breakpoints, record execution, replay state. See example scripts.
• YAML Workflows: vsp workflow run pipeline.yaml — CI/CD automation with variable substitution, step chaining, and error handling. See example workflows.
• Bootstrap from CLI: vsp install abapgit + vsp install zadt-vsp — deploy dependencies to SAP systems directly from the command line. No SAP GUI needed.

Key Features

• Classic RFC without the SAP SDK — vsp rfc and the rfc action of the SAP MCP tool call any RFC-enabled function module over the gateway, in pure Go.

Quick Start

#Download binary from releases
curl -LO https://github.com/oisee/vibing-steampunk/releases/latest/download/vsp-linux-amd64
chmod +x vsp-linux-amd64

#Or build from source
git clone https://github.com/oisee/vibing-steampunk.git && cd vibing-steampunk
make build

Windows 11 with VS Code + Claude Code extension:

1. Get the latest vsp release:

https://github.com/oisee/vibing-steampunk/releases.

If you have trouble downloading executable files in your browser, use curl -o url or wget to download the file. Name the file vsp.exe.

Put the file in a local folder and open the folder in VS Code.

Add the vsp folder to your PATH environment variable for your user. Either through command line or Windows Registry Editor regedit. Add the vsp folder to KEY_CURRENT_USER\Environment\Path.

Restart your VS Code to recognize the updated PATH before progressing to the next steps.

2. Initialize the config files:

Open a terminal in VS Code, then run ./vsp config init to create config template files:

• .env.example
• .vsp.json.example
• .mcp.json.example

3. Adjust your config files:

Make sure you delete the comment lines. Refer to the example files in this README.

4. Set up authentication

For basic auth: Set up a password for your user to allow for basic authentication. Go to SU01 > Logon Data, generate an initial password. Then log in again (without SNC/SSO in SAPGUI) and change the initial password. You are now set up for basic authentication via config file in vsp. Set your environment variables SAP_USER and SAP_PASSWORD accordingly.

You now need to obtain the SAP hostname for your SAP_URL environment variable: Log in to any web-based application (e.g. Fiori Launchpad) and obtain the URL from your browser. Attention: SAP_URL is not not your message/group server from SAP Logon!

Alternatively use cookie authentication: If you cannot set a password for your user, you may still use cookie authentication to access your SAP system from vsp.

Extract cookies manually and save them in cookies.txt in your vsp folder. Use cookies SAP_SESSIONID_SYS_CLI and sap-usercontext on your previously determined URL (caution: use https:// prefix for secure connections). Refer to below guide on how to manually extract cookies from your browser.

Template cookie file:

# Netscape HTTP Cookie File
# https://curl.haxx.se/rfc/cookie_spec.html

https://your.domain.com	FALSE	/	TRUE	0	SAP_SESSIONID_SYS_CLI  YOUR_CONTENT
https://your.domain.com	FALSE	/	TRUE	0	sap-usercontext        YOUR_CONTENT

Replace the hostname, SYS with your system ID (e.g. DS1) and CLI with your client number (e.g. 100).

For BTP/Cloud based systems: Use cookies __VCAP_ID__ and JSESSIONID on your domain https://xyz.ondemand.com. This also works for BTP trial accounts. Also refer to this article.

Obtaining cookies from your browser session:

The easiest way to do so is to use Edge as it allows you to display cookie contents from its settings page. From there you can copy & paste them into the newly created cookies.txt file.

Open any transaction in WebDynpro or Fiori Launchpad. For older environments like ECC it should work with BRF+ transactions that open in a browser. Login with your credentials. Once logged in it’s a matter of extracting the created session cookies.

In Edge, go to Settings > Privacy, search and services > Cookies > See all cookies and site data. Search for your top-level domain. There should be two cookies for your system as described above (SAP_SESSIONID and sap-usercontext or VCAP_ID and JSESSIONID if your system is cloud-based). Copy the content values for each cookie to your local file and save.

The created cookies are session cookies. They will eventually expire after a timeout and the values in cookies.txt need to be updated. Usually Claude will tell you if this is the case.

5. Test the connection:

Use the terminal with this command: ./vsp -s dev search "zcl_*" --type CLAS --max 50.

You will get prompted with a list of found objects if the connection could be established.

CLI Coding Agents

VSP works with 8 CLI coding agents — not just Claude! Full setup guides with config templates:

Availability, pricing, and model lineups change quickly. Check the linked agent guides and official product docs before copying limits or plan claims into downstream docs.

Full setup guide with config examples | Русский | Українська | Español

For the new graph analysis capabilities, see Graph Guide.

CLI Mode

vsp works in two modes:

1. MCP Server Mode (default) - Exposes tools via Model Context Protocol for Claude
2. CLI Mode - Direct command-line operations without MCP

CLI Commands

# Source operations
vsp -s a4h source CLAS ZCL_MY_CLASS              # read source
vsp -s a4h source read CLAS ZCL_MY_CLASS          # same, explicit
vsp -s a4h source read CLAS ZCL_MY_CLASS --summary              # lines, bytes, sha256 — no body
vsp -s a4h source read CLAS ZCL_MY_CLASS --if-none-match   # "unchanged" or the source
vsp -s a4h source write CLAS ZCL_FOO < file.abap  # write from stdin
vsp -s a4h source edit CLAS ZCL_FOO --old "X" --new "Y"  # surgical edit
vsp -s a4h source context CLAS ZCL_FOO            # source + dependency contracts
vsp -s a4h context CLAS ZCL_FOO                   # shortcut for above

# Search
vsp -s a4h search "ZCL_*"
vsp -s dev search "Z*ORDER*" --type CLAS --max 50

# Graph analysis
vsp -s a4h graph CLAS ZCL_FOO                      # call graph
vsp -s a4h graph co-change CLAS ZCL_FOO           # transport-based co-change
vsp -s a4h graph co-change PROG ZREPORT --format json
vsp -s a4h graph where-used-config ZKEKEKE        # TVARVC readers (heuristic)
vsp -s a4h graph where-used-config ZKEKEKE --format mermaid > config.mmd
vsp -s a4h loads ZCL_FOO                           # D010INC: what must be loaded for this to run
vsp -s a4h loads ZDEMO_GROUP --direction loaded-by # and what pulls this in
vsp -s a4h examples FUNC Z_CALCULATE_TAX           # real call sites, ranked, from caller source
vsp -s a4h examples CLAS ZCL_TRAVEL --method GET_DATA

# Runtime errors and the application log
vsp -s a4h dumps --since 2026-08-01                # newest first
vsp -s a4h dumps --group                           # what keeps failing
vsp -s a4h dumps --similar latest                  # the same bug, its siblings, its neighbourhood
vsp -s a4h dumps --explain latest --tolerance 10m  # stack + ranked log around it
vsp -s a4h applog --program ZCL_ORDER_POST --top 20
vsp -s a4h applog --user TESTUSER --since 2026-08-01
vsp -s a4h applog --object ZDEMO_LOG --messages    # the messages too, decoded from BALDAT
vsp -s a4h jobs list --since 2026-09-01 --status A  # what was cancelled, with steps and spools
vsp -s a4h jobs log ZDEMO_NIGHTLY 22554500          # the job log, over XBP
vsp -s a4h spool list --job ZDEMO_NIGHTLY           # what the job's steps printed
vsp -s a4h spool read 27302                         # the list, decoded from TemSe
vsp -s a4h spool export --since 2026-09-01 --out ./spool
vsp -s a4h variants ZDEMO_NIGHTLY_RUN MONTH_END      # every field, its label, its value
vsp -s a4h fmtest ZDEMO_CALCULATE_TAX                # SE37's saved test data
vsp -s a4h docs read FU BAL_LOG_CREATE               # SE61 documentation as Markdown
vsp -s a4h docs img "cleanup job"                    # where in the IMG, and which activity
vsp -s a4h texts set ZDEMO_RUN P_DEVC="Package to scan"  # selection texts, a plan first
vsp -s a4h description ZDEMO_RUN "What the report does"  # SE38's title, without touching the source
vsp update                                           # the latest release, verified, in place of this binary
vsp update --repo owner/name                         # from a different repository than the one this build was released from

# Cluster tables — what only IMPORT could read, decoded here
vsp -s a4h cluster read INDX --where "relid = 'ZV'" --schema
vsp -s a4h cluster read INDX --where "relid = 'ZD'" --layout ZDEMO_S_HEADER   # names from DD03L
vsp -s a4h cluster read STXL --where "tdname = 'ZDEMO_TEXT'"                 # SAPscript text
vsp cluster decode baldat.txt --layout applog     # an SE16H export, offline

# Testing & code quality
vsp -s a4h test CLAS ZCL_MY_CLASS                 # run unit tests
vsp -s a4h test --package '$TMP'                  # package-level tests
vsp -s a4h atc CLAS ZCL_MY_CLASS                  # ATC code check

# Deployment
vsp -s a4h deploy zcl_test.clas.abap '$TMP'       # deploy file to SAP
vsp -s a4h export '$ZORK' '$ZLLM' -o packages.zip # export abapGit ZIP

# Bootstrap SAP system (no SAP GUI needed)
vsp -s a4h install abapgit                        # install abapGit
vsp -s a4h install zadt-vsp                       # install ZADT_VSP handler
vsp -s a4h install list                           # show installable components

# Transport management
vsp -s a4h transport list                         # list transports
vsp -s a4h transport get A4HK900094               # transport details

# System management
vsp systems                                       # list configured systems
vsp config init                                   # create example configs

# Self-check: which advertised capabilities actually answer
vsp sweep --reach-only                            # offline; is everything registered and routed
vsp -s a4h sweep --strict                         # read-only probes against a system, non-zero exit on findings

# Start ABAP LSP server (for Claude Code / editors)
vsp lsp --stdio

Graph-MVP highlights:

• vsp graph co-change for transport-based co-change analysis
• vsp graph where-used-config for heuristic TVARVC usage analysis
• SAP(action="analyze", params={"type":"co_change", ...}) for MCP co-change
• SAP(action="analyze", params={"type":"impact", ...}) for reverse dependency impact
• SAP(action="analyze", params={"type":"where_used_config", ...}) for MCP TVARVC usage

System Profiles (.vsp.json)

Configure multiple SAP systems in .vsp.json:

{
  "default": "dev",
  "systems": {
    "dev": {
      "url": "http://dev.example.com:50000",
      "user": "DEVELOPER",
      "client": "001"
    },
    "a4h": {
      "url": "http://a4h.local:50000",
      "user": "ADMIN",
      "client": "001",
      "insecure": true
    },
    "prod": {
      "url": "https://prod.example.com:44300",
      "user": "READONLY",
      "client": "100",
      "read_only": true,
      "cookie_file": "/path/to/cookies.txt"
    }
  }
}

Password Resolution:

• Set via environment variable: VSP__PASSWORD (e.g., VSP_DEV_PASSWORD)
• Or use cookie authentication: cookie_file or cookie_string
• Or let the browser do it: "auth": "sso" — see Browser SSO

Config Locations (searched in order):

1. .vsp.json (current directory)
2. .vsp/systems.json
3. ~/.vsp.json
4. ~/.vsp/systems.json

Finding a System Before You Can Configure It

Nothing on a workstation knows which port a system serves ADT on. SAP Logon's landscape file describes SAP GUI connectivity and carries no HTTP at all; Eclipse ADT asks the person setting up the project. The convention — HTTPS at 443nn, HTTP at 80nn — is a starting guess and often wrong, because a system behind a web dispatcher answers on 443 instead.

vsp detect sap.example.com          # scan, and print the config for what answered
vsp detect DEV --all                # by system id; --all sweeps every conventional port

It reports how far each port got, which separates questions that go to different people: adt (the port is right, credentials are a separate matter), SAP without ADT (the port is right and the ICF node is off — that is a conversation with basis), a certificate for another host (the port is right and the name is not — and the scan follows that name, since an application server behind a dispatcher presents the dispatcher's certificate). TLS is preferred over plain HTTP, and when only plain answers it says so.

vsp landscape list reads the systems SAP Logon already knows — including the shared one on a company file server, from SAP Logon's own cache rather than over the share — and vsp landscape import turns them into configuration.

Knowing What a System Supports

Two SAP releases answer the same ADT request differently, in ways nothing documents and no feature flag captures: a resource present on one is missing on the other, and a content type accepted by one is refused by the other.

vsp -s dev compat                   # quick: what decides routing, in seconds
vsp -s dev compat --full            # the whole surface
vsp -s dev compat --against prod    # only what the two disagree about

It reports, per capability, which route the system supports and which to prefer — because a table of 200s and 404s leaves the reader to work that out again. Measured across an S/4-generation and an ERP-generation system, five of six capabilities route the same way; RFC is the one that does not.

Browser SSO (Entra, SAML, Kerberos)

Some systems have no password to give: sign-in goes through a browser, and what comes back is a session that expires in hours. Set "auth": "sso" and vsp keeps one for itself — capturing a session on demand, noticing when the server stops accepting it, and capturing another. Nothing that expires is written into any config file.

{
  "systems": {
    "dev": { "url": "https://sap.example", "client": "100", "auth": "sso" }
  }
}

vsp -s dev sso login       # first sign-in, in a visible window
vsp -s dev sso status --check   # what is cached, and whether it still works
vsp -s dev search 'ZCL_*'  # from here on, authentication takes care of itself

The session is cached in ~/.vsp/sso/.json, owner-only. Optional tuning lives in an sso block: trigger_url (the page whose loading starts the redirect — the ADT root by default), profile (browser profile directory), helper (path to vsp-sso.exe), and on_expiry — "window" opens a sign-in window when a silent refresh needs a human, "error" reports what to run instead, which is the better choice where nobody is watching a screen.

Under WSL the browser step runs as a Windows process. This is not a convenience: on tenants with device-based Conditional Access the credential that proves the device — an Entra Primary Refresh Token — is held by the Windows account broker and cannot be reached from Linux, so a browser started on the Linux side loops on the identity provider forever. vsp stages a small helper (vsp-sso.exe, from make sso-helper) onto the Windows side, runs it through interop, and reads the cookies back over its stdout. Only cookies cross.

--sso is authoritative: any SAP_USER/SAP_PASSWORD in the environment is ignored, because basic auth would win in the transport and take the automatic recovery down with it.

Transport command: ADT through a helper process

Some systems are reachable only through a program that does the sign-in itself, for example a helper that logs on with a corporate SSO. With a transport command, vsp sends every ADT HTTP request to that helper over its stdin and stdout and opens no connection and no local port of its own. The helper reaches SAP however it can and answers each request.

vsp --url https://sidecar.invalid --transport-cmd /opt/tools/adt-helper --transport-arg --profile --transport-arg dev
export SAP_TRANSPORT_CMD='["/opt/tools/adt-helper", "--profile", "dev"]'   # same, as a JSON array

{
  "systems": {
    "dev": { "url": "https://sidecar.invalid", "client": "100",
             "transport_cmd": ["C:\\tools\\adt-helper.exe", "--profile", "dev"] }
  }
}

• The helper authenticates. A transport command next to user/password, cookies, browser-auth, SAML or SSO is refused. This includes SAP_USER/SAP_PASSWORD in the environment.
• The URL is still required, because ADT paths and the Host header are built from it. https://sidecar.invalid is a fine placeholder when only the helper knows the real address.
• transport_cmd is honoured only in ~/.vsp.json or ~/.vsp/systems.json. The same key in a .vsp.json in the working directory is refused, and so is SAP_TRANSPORT_CMD from a .env file, because a project file must not be able to make vsp run a program. "Home" means HOME (USERPROFILE on Windows) as the vsp process received it, before any .env is read. It must be an absolute path. Outside Windows, the file must not be writable by group or others.
• The ZADT_VSP WebSocket features can't go through the pipe, and they refuse with "not available over a transport command". Classic RFC needs an explicit rfc_host (or --rfc-host) rather than the placeholder URL.

Writing a helper. The protocol is the same in both directions:

1. A frame is a 4-byte big-endian unsigned length followed by exactly that many bytes. Those bytes are one raw HTTP/1.1 message. The limit is 64 MiB per frame.
2. vsp writes a request in origin form (GET /sap/bc/adt/...?sap-client=100 HTTP/1.1) with a Host header and its other headers (cookies, X-CSRF-Token, X-sap-adt-sessiontype, ...). Its body always has a Content-Length; it is never chunked.
3. The helper sends the request on to SAP and writes back one frame holding the complete response: status line, headers (including Set-Cookie, which vsp keeps in its cookie jar) and the whole body, either with Content-Length or chunked.
4. Only one request is in flight. vsp writes the next frame only after it has read the answer to the previous one.
5. When its stdin reaches EOF, the helper exits. vsp closes stdin on shutdown and kills the helper three seconds later. On Windows the helper is put into a Job Object that ends it with vsp. That happens just after the helper starts, so it must start no child processes before the first frame arrives.
6. The helper gets vsp's environment minus anything whose name looks like a secret (PASSWORD, PASSWD, SECRET, TOKEN, COOKIE) and minus vsp's own logon settings (SAP_USER, SAP_PASSWORD, VSP_*_PASSWORD, SAP_RFC_*). It brings its own configuration.
7. The helper writes only frames to stdout. Logs go to stderr, which vsp passes through and quotes (the last 20 lines) when the helper fails. Secrets such as tokens, cookies and passwords must never be printed there.

If the helper exits, writes a malformed or oversized frame, or a request is abandoned half-way (timeout, cancel), vsp kills the helper and reports the transport as broken. It does not restart it, because a new helper would mean a new session and the old session's locks would be lost. Restart vsp instead.

SNC single sign-on through sapnwrfc.dll (Windows)

On Windows, vsp.exe can reach a system the way SAP GUI does: over RFC with SNC and Kerberos, using SAP's own NetWeaver RFC library. No password, cookie or browser is involved, and no extra program: vsp runs itself as its own transport command (vsp snc-serve) and carries ADT over RFC (SADT_REST_RFC_ENDPOINT). The library is loaded from pure Go, so the build stays CGO_ENABLED=0.

What you need:

• sapnwrfc.dll, from the SAP NW RFC SDK 7.50 for Windows x64. Download it from the SAP Software Center (an S-user with download rights is needed; search for "SAP NW RFC SDK"). vsp never ships the DLL. Keep the SDK's lib folder together: its other DLLs are loaded from beside sapnwrfc.dll (and from System32), never from the working directory or PATH.
• The SNC library SAP GUI uses, usually gx64krb5.dll (Kerberos).
• A SAP Logon entry for the system with SNC switched on. vsp reads it from SAPUILandscape.xml, including its ``s, and takes only the exact entry you name.

{
  "systems": {
    "dev": {
      "snc": {
        "dll": "C:\\SAP\\nwrfcsdk\\lib\\sapnwrfc.dll",
        "snc_lib": "C:\\Program Files\\SAP\\FrontEnd\\SecureLogin\\lib\\gx64krb5.dll",
        "connection": "DEV - Development",
        "system": "DEV",
        "client": "100",
        "user": "TESTUSER",
        "production": false
      }
    }
  }
}

vsp -s dev search "ZCL_*"

dll and snc_lib may be left out: dll then means sapnwrfc.dll beside vsp.exe, and snc_lib the SNC_LIB_64 variable that SAP GUI sets, read from the user's environment in the registry, then the machine's. It is not read from vsp's own process environment, which a project's .env feeds, and a %VAR% value is not expanded: name snc_lib then. SNC_LIB is not read; it names the 32-bit library, which a 64-bit vsp.exe cannot load.

Optional keys: landscape (an absolute path to SAPUILandscape.xml; default: SAP GUI's own, via SAPLOGON_LSXML_FILE or %APPDATA%\SAP\Common), logon_timeout (default 45s), request_timeout (default 60s), production (required, see below), allow_data_preview (forward data preview SELECTs on a production system too) and verbose (one stderr line per request).

• Home directory only. The snc block names a DLL that vsp loads, so it is honoured only in ~/.vsp.json or ~/.vsp/systems.json, by the same rule as transport_cmd. In a .vsp.json in the working directory it is refused.
• Windows only. Elsewhere vsp refuses the block. On Linux or macOS, use transport_cmd with an external helper instead.
• Exclusive. It cannot be combined with transport_cmd, user/password, cookies or auth: sso. vsp fills in the rest: url defaults to https://snc.invalid (nothing connects to it), client comes from the block, expect defaults to SYSTEM.CLIENT/USER, and the system is read-only.
• The identity is checked twice. The logon is refused unless the authenticated system, client and user match the block. vsp's own expect check runs again on the first request. On a release without ADT's system information resource, snc-serve answers it from the RFC logon's identity, marked X-Vsp-Snc-Identity: rfc-logon, because the T000 fallback cannot always tell the system ID.
• Read-only, stricter on production. GET on an allowlist of ADT read paths goes to SAP: discovery, repository, sources, DDIC, packages, transports and dumps. production must be given, so a forgotten flag cannot open a production system. With "production": false, a row-capped data preview SELECT is also forwarded, but never one that names a credential table. On a production system it is forwarded only with allow_data_preview. vsp's own identity check (one row of T000, for releases without the system information resource) is always forwarded. Everything else, including every write, is answered 403 locally and never reaches SAP: the channel has no stateful session and no locks. Cookies, credentials and session headers are not forwarded.
• No retries. A failed logon or RFC call stops the channel. Nothing is retried, because a retried Kerberos or SNC failure gains nothing. Restart vsp.
• No logs on disk, no secrets in errors. The SDK runs in a separate worker process (vsp.exe again) whose working directory holds only a sapnwrfc.ini that turns tracing off and is locked against file creation. Its stderr is discarded. Errors carry RFC return codes and fixed stage names, never SAP's message text, hosts or partner names.

For the MCP server, name the system; it takes the logon, client, identity pin and read-only from the snc block, with the same checks as the CLI:

{
  "command": "C:\\tools\\vsp.exe",
  "args": ["-s", "dev"]
}

A URL, user, password or transport command given as well (flags or SAP_*) is refused rather than mixed in.

From WSL, a Linux vsp can use the Windows build as its helper: the Windows process holds the Kerberos ticket of your Windows logon and reaches the network as Windows does. In ~/.vsp.json on the Linux side:

"dev": {
  "url": "https://snc.invalid", "client": "100", "read_only": true,
  "expect": "DEV.100/TESTUSER",
  "transport_cmd": ["/mnt/c/tools/vsp.exe", "snc-serve",
    "-system", "DEV", "-client", "100", "-user", "TESTUSER",
    "-connection", "DEV - Development",
    "-dll", "C:\\tools\\sapnwrfc.dll",
    "-snc-lib", "C:\\Program Files\\SAP\\FrontEnd\\SecureLogin\\lib\\gx64krb5.dll"]
}

MCP Server Configuration

CLI Flags

vsp --url https://host:44300 --user admin --password secret
vsp --url https://host:44300 --cookie-file cookies.txt
vsp --url https://host:44300 --sso --sso-system dev   # browser SSO, self-refreshing
vsp --mode expert          # Enable all 148 tools
vsp --mode hyperfocused    # Single SAP tool (~200 tokens instead of ~40K)

Environment Variables

export SAP_URL=https://host:44300
export SAP_USER=developer
export SAP_PASSWORD=secret
export SAP_CLIENT=001
export VSP_CACHE=true              # keep read answers; see "Response cache"
export VSP_CACHE_PATH=.vsp-cache/dev.db
export VSP_CACHE_TTL=10m

Response cache

VSP_CACHE=true (or "cache": true on a system in .vsp.json) keeps the answers to reads: every GET, and data preview queries on the tables that change with development rather than with business — DD03L, TADIR, CROSS, T100, the documentation tables. Kept for VSP_CACHE_TTL (10 minutes) and dropped, all of it, on any write through the client, so an edit is never followed by a stale read. Queries on logs, spool and jobs are never kept.

In memory by default, which is what an MCP session wants: the same class is read once, not on every turn. With `VSP_CACHE
