semiotic

A React data visualization library designed for AI-assisted development and streaming data.

Start with a small chart component. Add network graphs, streaming data and coordinated views when the task needs them. Structured schemas, diagnostics and rendering evidence help coding assistants implement, check and repair chart configurations.

Work through a complete task: check category totals, maintain a live chart, or correct a published chart. The source task packets identify their build and evidence scope; source availability does not establish installed or deployed parity.

What's New in 3.12.1

3.12.1 extends network perspectives to the Atlas readers and improves projected layout sizing, annotation anchors, and static SVG precision. Placement components retain their identity across package entries, and semioticVite() removes unused worker assets from Vite 7 builds while preserving workers that are used.

See the changelog for the full list and SVG compatibility notes.

Why Semiotic

Semiotic is a data visualization library for React that combines broad chart coverage with AI tooling. It supports network graphs, streaming data, statistical distributions and coordinated views, with schemas, examples and diagnostics for implementing and checking each task. Check the project's existing dependencies first: extending its current charting library may be the best fit for a small change.

Built for AI-assisted development

Semiotic provides a workflow for generating, checking and repairing chart configurations. The July 27, 2026 evaluation reports model- and task-specific results; it does not guarantee first-try correctness.

• semiotic/ai — a single import with the schema-backed chart capability catalog (XY, ordinal, network, realtime, geo, value, and portable recipes), optimized for LLM code generation. See ai/surface-manifest.json for the generated current inventory. Named imports now tree-shake across published chunks. Prefer family subpaths (semiotic/xy, semiotic/geo, semiotic/value, …) in production code to keep the intended chart family explicit; the cold-consumer table below reports initial-load and on-demand costs.
• ai/schema.json — machine-readable prop schemas for every component
• npx -y -p semiotic semiotic-mcp — an MCP server for tool-based chart rendering in any MCP client
• npx -p semiotic semiotic-ai --doctor — validate component + props JSON from the command line with typo suggestions and anti-pattern detection
• diagnoseConfig(component, props) — programmatic anti-pattern detector with actionable fixes, spanning validation, encoding, accessibility, and misleading-design (deception) checks
• auditData(component, props, data?) — chart-aware numeric preflight for inputs that pass schema validation but break the math: non-finite values, zero-span domains, invalid log inputs, negative size geometry, unsafe normalized totals, and scale-dominating outliers. Returns bounded row evidence and flows into diagnoseConfig, Chart Clinic, CLI doctor, and opt-in ChartContainer notifications
• AGENTS.md — concise repository workflow shared by modern coding agents; CLAUDE.md imports it and Copilot receives a short compatibility bridge
• ai/reference.md — complete on-demand product reference, kept out of always-loaded coding-agent context
• llms.txt — machine-readable documentation following the emerging standard

Every chart includes a built-in error boundary, dev-mode validation warnings with typo suggestions, and accessibility features (canvas aria-label, keyboard-navigable legends, keyboard live-region announcements, SVG /) so AI-generated code fails gracefully with actionable diagnostics instead of a blank screen.

Accessibility is a release surface

The European Accessibility Act has applied to covered products and services since 28 June 2025. A chart library cannot certify an application's legal compliance: scope, content, surrounding controls, testing, and national enforcement remain the application owner's responsibility. Semiotic supplies testable infrastructure for that work: keyboard interaction, accessible data tables, layered descriptions, structured navigation, reduced-motion and forced-colors paths, and WCAG-derived contrast tests for shipped theme presets. See the Accessibility docs and run the application's own assistive-technology and user testing.

Beyond standard charts

Network visualization. Force-directed graphs, Sankey diagrams, chord diagrams, tree layouts, treemaps, circle packing, and orbit diagrams — all as React components with the same prop API as LineChart.

Streaming data. Realtime charts render on canvas at 60fps with a ref-based push API. Rapid network edge pushes coalesce into one layout per animation frame, while read/mutation methods preserve synchronous read-after-write semantics. Built-in decay, pulse, and staleness encoding for monitoring dashboards.

Coordinated views. LinkedCharts provides hover cross-highlighting, brush cross-filtering, coordinate-based linked crosshairs, and selection synchronization across any combination of chart types through shared selection state.

Geographic visualization. Choropleth maps, proportional symbol maps, flow maps with animated particles, and distance cartograms — all canvas-rendered with d3-geo projections, zoom/pan, tile basemaps, and drag-rotate globe spinning.

Statistical summaries. Box plots, violin plots, swarm plots, histograms, LOESS smoothing, forecast with confidence envelopes, and anomaly detection. Marginal distribution graphics on scatterplot axes with a single prop.

First-class annotations. Annotations are data-bound objects, not post-hoc artwork. Labels, callouts, thresholds, enclosures, statistical overlays, and React widgets move with the chart and render through browser, SSR, and export paths. Opt into placement, hierarchy, density, progressive disclosure, audience-aware amount, provenance, and editorial lifecycle when the chart needs to communicate more than its encoding alone.

Choose the API layer

Chart HOCs register only the mark plugins they need. Direct StreamXYFrame loads the remaining built-ins on first client paint. Call registerBuiltInXYPlugins() from semiotic/xy or semiotic/realtime/core before the first render when SSR or the first frame must include marks.

Every Chart component accepts a frameProps prop to access the underlying Frame API without leaving the simpler interface.

Serialization and interop

Charts serialize to JSON and back: toConfig, fromConfig, toURL, copyConfig, configToJSX. Have Vega-Lite specs? fromVegaLite(spec) translates them to Semiotic configs — works with configToJSX() for full round-trip from notebooks and AI-generated specs.

Need an external pitfall review? The experimental unstable_toDataPitfallsChain() builds a dependency-free chain input for datapitfalls, combining the Semiotic config, JSX, reader grounding, diagnostics, accessibility audit, and optional rendered SVG/image evidence:

import { unstable_toDataPitfallsChain } from "semiotic/experimental"
import { detectPitfalls } from "datapitfalls"

const input = unstable_toDataPitfallsChain("LineChart", props, {
  narrative: "Monthly sales are accelerating.",
  rendered: { svg, evidence },
})

const report = await detectPitfalls(input, { apiKey: process.env.ANTHROPIC_API_KEY })

The return path stays dependency-free too. Use whole-chart findings as ChartContainer notifications, and only turn findings into annotations after your app can anchor them to marks or semantic positions:

import { ChartContainer } from "semiotic"
import { LineChart } from "semiotic/xy"
import {
  unstable_toDataPitfallsAnnotations,
  unstable_toDataPitfallsNotifications,
} from "semiotic/experimental"

const notifications = unstable_toDataPitfallsNotifications(report)
const annotations = unstable_toDataPitfallsAnnotations(report, {
  anchorFor: (finding) =>
    finding.ruleId === "truncated-axis" ? { x: 9, y: 9000 } : null,
})




When to use something else

Need a standard bar or line chart for a dashboard you'll never need to customize beyond colors and labels? Recharts has a larger ecosystem and more community examples. Need GPU-accelerated rendering for millions of data points? Apache ECharts handles that scale.

Semiotic is for projects that outgrow those libraries — when you need network graphs alongside time series, streaming data alongside static snapshots, or coordinated views across chart types.

Install

npm install semiotic

Requires React 18.1+ or React 19.

Quick Examples

Coordinated Dashboard

Hover one chart and highlight the same data in another through a shared selection:

import { LinkedCharts, Scatterplot, BarChart } from "semiotic"





Streaming Metrics with Decay

Live data fades old points, flashes new ones, flags stale feeds:

import { RealtimeLineChart } from "semiotic"

const chartRef = useRef()
chartRef.current.push({ time: Date.now(), value: cpuLoad })

Network Graphs

Force-directed graphs and Sankey diagrams — same API as LineChart:

import { ForceDirectedGraph, SankeyDiagram } from "semiotic"

Geographic Visualization

Choropleth maps, flow maps, and distance cartograms with canvas rendering, zoom/pan, tile basemaps, and animated particles:

import { ChoroplethMap, FlowMap, DistanceCartogram } from "semiotic/geo"

Streaming System Monitor

Live service topology with threshold alerting and click-to-inspect:

import { StreamNetworkFrame, ChartContainer, DetailsPanel, LinkedCharts } from "semiotic"

const chartRef = useRef()
chartRef.current.push({ source: "API", target: "Orders", value: 15 })



        {(datum) =>
{datum.id}: {datum.value} req/s
}

    }>
     n.value, warning: 100, critical: 250 }}
    />


Standard Charts

Line, bar, scatter, and area charts share the same accessor-driven API:

import { LineChart, BarChart } from "semiotic"

All Chart Components

Vega-Lite Translation

Paste a Vega-Lite spec, get a Semiotic chart:

import { fromVegaLite } from "semiotic/data"
import { configToJSX, fromConfig } from "semiotic"

const config = fromVegaLite({
  mark: "bar",
  data: { values: [{ a: "A", b: 28 }, { a: "B", b: 55 }] },
  encoding: {
    x: { field: "a", type: "nominal" },
    y: { field: "b", type: "quantitative" },
  },
})

// Render directly
const { componentName, props } = fromConfig(config)
// → componentName: "BarChart", props: { data, categoryAccessor: "a", valueAccessor: "b" }

// Or generate JSX code
configToJSX(config)
// →

Supports bar, line, area, point, rect, arc, tick marks with encoding translation for color, size, aggregation, and binning.

Conversation Arc Telemetry

Capture and replay the path an AI-assisted chart session took:

import {
  createLocalStorageConversationArcSink,
  enableConversationArc,
  getConversationArcStore,
  loadConversationArc,
  registerConversationArcSink,
} from "semiotic/ai"

const sink = createLocalStorageConversationArcSink({ key: "my-app:arc" })
registerConversationArcSink(sink)
enableConversationArc({ sessionId: "session-abc" })

getConversationArcStore().record({ type: "chart-rendered", component: "LineChart" })
loadConversationArc(sink.load(), { enabled: false })

Bundle Sizes

Semiotic ships 41 stable JavaScript entry points (40 subpaths plus the root). Don't import from "semiotic" unless you need everything — use the smallest sub-path that matches your charts or tooling.

Custom network layouts can opt into a virtual zoom/pan viewport through semiotic/network/zoom. It exports ZoomableNetworkCustomChart and projected-size/LOD hooks; ordinary chart imports exclude its gesture and LOD runtime.

The numbers below are first-party artifact cost: the gzip size of Semiotic's own code for each sub-path. They exclude React and other runtime dependencies, and each row counts every chunk the entry can reach, including code loaded only on demand, so they are not a prediction of a cold application bundle. Do not add artifact rows to estimate an app: dependency resolution and cross-import deduplication happen in the consumer bundler and are measured separately below.

Cold-consumer named imports

The table above is first-party artifact cost, not an application bundle. The generated table below measures a different thing: a fresh consumer bundles one retained named import from a packed semiotic tarball through the public export path, with code splitting as an application build does. Initial load is what a page downloads before the chart renders; on demand is code fetched only when a feature needs it. It includes Semiotic and its resolved runtime dependencies, but externalizes React/React DOM and optional adapter peers that the host application owns. Each row starts cold, so use it to compare one public import choice—not to add together an application's rows. The checked machine-readable baseline is benchmarks/setup/cold-consumer-imports.json; refresh it after a production build with npm run docs:cold-consumer.

Method: fresh npm pack --ignore-scripts tarball → temporary consumer → minified/tree-shaken Rolldown (Vite's bundler) ESM build with code splitting and a production NODE_ENV → gzip -9 per file. Initial load counts the entry and its statically imported chunks; on demand counts chunks fetched only when a feature needs them (brushing, marginal graphics, animated transitions, a bare frame's built-in layouts). React/React DOM and optional adapter peers are external; Semiotic and its resolved runtime dependencies are included.

Line-boundary interpretation: the retained named import from semiotic/line emits 356.3 KiB raw versus 356.3 KiB from semiotic/xy; gzip differs by 0.1 KiB (0.1%). Tree-shaking converges both paths on the same LineChart implementation graph. Treat semiotic/line as a narrower API/direct-ESM artifact boundary, not an application-bundle saving. Do not add another per-chart entry until its packed named import beats the family path by both 10 KiB gzip and 7%.

d3 packaging model: Semiotic externalizes the twelve d3 modules it imports and declares them as normal runtime dependencies. Consumers do not need to install d3 packages manually; their bundler resolves, deduplicates, and tree-shakes that dependency graph. A packed webpack comparison favored this model in three of four representative chart families, and a Next 16 webpack route was 22.7 KiB gzip smaller than the fully bundled alternative. The one bundled win, Sankey, was only 0.4 KiB gzip. This choice retains a 22-package, 1.9 MB unpacked d3 install closure in exchange for smaller common application graphs and an ordinary dependency contract. The checked policy is npm run check:d3-packaging; the reproducible evidence is in benchmarks/setup/d3-packaging.json and can be regenerated with npm run measure:d3-packaging -- --toolchain-root after installing webpack and Next in that isolated toolchain directory.

// Import from the sub-path, not from "semiotic"
import { LineChart } from "semiotic/xy"
import { BarChart } from "semiotic/ordinal"
import { SankeyDiagram } from "semiotic/network"
import { ChoroplethMap } from "semiotic/geo"

Tree-shaking & multi-subpath imports: Family entries (semiotic/xy, semiotic/network, semiotic/ai, …) are built as one ESM graph with shared chunks. Stream frames, renderers, and other common code ship once and are imported by every entry that needs them — so combining semiotic/ai + semiotic/xy + semiotic/network does not mean paying for three full copies of the runtime. The package is marked "sideEffects": false, so modern bundlers keep only the named exports you retain (e.g. LineChart + suggestCharts). Prefer family subpaths for clarity; import AI helpers from semiotic/ai or the lighter semiotic/ai/core when you do not need the chart catalog.

When to use "semiotic": Fine when you want one import for mixed families. Shared chunks prevent duplicated runtime code across family subpaths; the cold-consumer table above is the better guide for a single named import.

CommonJS compatibility note: require("semiotic/xy") loads the shared CommonJS client bundle (about 2.1 MB before compression) so React contexts stay singletons across family imports. Prefer ESM imports in browser builds when bundle size matters; splitting that CJS client without a context-identity contract would be unsafe.

TypeScript

Built with strict: true. Full type definitions ship with the package. Generics for type-safe accessors:

interface Sale { month: number; revenue: number }


  data={sales}
  xAccessor="month"    // TS validates this is keyof Sale
  yAccessor="revenue"
/>

Server-Side Rendering

All chart components render SVG automatically in server environments — no special imports or configuration needed. Non-streaming chart HOCs can be imported and rendered directly from a Next.js Server Component: Semiotic's "use client" directive defines the package boundary, so the importing page does not need its own wrapper or directive. Props crossing that boundary must remain serializable; add an app-owned client wrapper only when you introduce hooks, callback props, browser state, or a push-driven streaming chart.

// app/dashboard/page.tsx — a Next.js Server Component
import { LineChart } from "semiotic/xy"

// Server: renders

Example: render a ChatGPT Apps widget

Tool: renderInteractiveChart
Args: {
  "component": "BarChart",
  "props": {
    "title": "Revenue by Quarter",
    "data": [
      { "quarter": "Q1", "revenue": 120 },
      { "quarter": "Q2", "revenue": 180 }
    ],
    "categoryAccessor": "quarter",
    "valueAccessor": "revenue"
  }
}
→ Returns: structured chart summary for the model + hidden SVG/widget metadata for ChatGPT.

Example: diagnose a broken config

Tool: diagnoseConfig
Args: { "component": "LineChart", "props": { "data": [] } }
→ Returns: ✗ [EMPTY_DATA] data is an empty array — Fix: provide at least one data point

Example: report an issue

Tool: reportIssue
Args: {
  "title": "Bug: BarChart tooltip shows undefined for custom accessor",
  "body": "When using valueAccessor='amount', tooltip displays 'undefined'.\n\ndiagnoseConfig output: ✓ no issues detected.",
  "labels": ["bug"]
}
→ Returns: Open this URL to submit the issue: https://github.com/nteract/semiotic/issues/new?...

CLI alternative

For quick validation without an MCP client:

npx -p semiotic semiotic-ai --list         # list components with import paths and renderability
npx -p semiotic semiotic-ai --list --json  # machine-readable component index
npx -p semiotic semiotic-ai --schema GaugeChart
npx -p semiotic semiotic-ai --suggest '{"data":[{"category":"A","value":10}],"intent":"comparison"}'
npx -p semiotic semiotic-ai --doctor       # validate component + props JSON
npx -p semiotic semiotic-ai --schema       # dump all chart schemas
npx -p semiotic semiotic-ai --compact      # compact schema (fewer tokens)

--doctor uses the full diagnoseConfig checks when dist is available and falls back to schema-only validation in clean source checkouts.

Where to find Semiotic for AI assistants

Semiotic is indexed by AI-coding-agent documentation tools so your assistant (Claude Code, Cursor, Cline, Copilot, etc.) can pull current docs and tools without copy-paste:

• Context7 — context7.com/nteract/semiotic (configured via context7.json)
• DeepWiki — deepwiki.com/nteract/semiotic
• GitMCP — gitmcp.io/nteract/semiotic (exposes the repo as an MCP endpoint directly)
• Official MCP Registry — search "semiotic" at registry.modelcontextprotocol.io

The Official MCP Registry is the canonical MCP directory record; it is distinct from acceptance into any assistant vendor's curated connector directory. Secondary-directory freshness and release ownership are tracked in MCP_DISTRIBUTION.md.

Agent-facing API surface:

• AGENTS.md is the concise repository development contract and CLAUDE.md imports it for Claude Code. These stay repository-local rather than shipping irrelevant contributor instructions to package consumers.
• ai/reference.md, ai/schema.json, ai/surface-manifest.json, ai/behaviorContracts.cjs, and agent-skill/semiotic-charts/SKILL.md are bundled in the npm tarball (see package.json#files). The reference is the on-demand product guide printed by npx -p semiotic semiotic-ai; the schema, manifest, contracts, and portable skill provide structured generation and validation guidance.
• semiotic.nteract.io/llms.txt + /llms-full.txt — deployed at the docs site per the llms.txt standard. Agents fetch the navigation map (llms.txt) or the full inlined docs (llms-full.txt) over HTTP; they're not part of the npm package itself.

Documentation

Interactive docs and examples

• Getting Started
• Charts — chart types with live examples
• Frames — full Frame API reference
• Features — axes, tooltips, interaction, responsive behavior, and composition
• Annotations — first-class annotation types, design guidance, provenance, and lifecycle
• Cookbook — advanced patterns and recipes
• Playground — interactive prop exploration

Upgrading

• Migration Guide — upgrading from v1.x or v2.x
• Changelog — full release history

Contributing

See CONTRIBUTING.md. Our community follows the nteract Code of Conduct.

Acknowledgments

Development of this library owes a lot to Susie Lu, Jason Reid, James Womack, Matt Herman, Shelby Sturgis, and Tristan Reid.

The Sankey layout engine is based on sankey-plus by Tom Shanley, which improved on his earlier d3-sankey-circular with better cycle detection, hierarchical arc stacking, and dynamic extent adjustment.

Semiotic icon based on an icon by Andre Schauer.
