torch_musa

Language: English | 中文

• Overview
• Usage
• Installation
  • Prerequisites
  • Docker Image
  • From Python wheels
  • From Source
• MUSA Supported Repositories
  • torchvision
  • torchaudio
  • Other Repositories
• Trouble Shooting
• License

Overview

torch_musa is an extended Python package based on PyTorch. Combined with PyTorch, users can take advantage of the strong power of Moore Threads graphics cards through torch_musa.

torch_musa's APIs are consistent with PyTorch in format, which allows users accustomed to PyTorch to migrate smoothly to torch_musa, so for the usage users can refer to PyTorch Official Doc, all you need is just switch the backend string from cpu or cuda to musa.

torch_musa also provides a bundle of tools for users to conduct cuda-porting, building musa extension and debugging. Please refer to README.md.

For some customize optimizations, like Dynamic Double Casting and Unified Memory Management, please refer to README.md.

If you want to write your layers in C/C++, we provide a convenient extension API that is efficient and with minimal boilerplate. No wrapper code needs to be written. Refer to ResNet50 example.

Usage

We recommend users refer to torchada, which enable your torch scripts written with CUDA run directly on our MUSA platform.

Now import torch would automatically load torch_musa, and in most cases, one just need to switch the backend from cuda to musa:

import torch
torch.musa.is_available()  # should be True

# Creating tensors:
a = torch.tensor([1.2, 2.3], dtype=torch.float32, device='musa')
b = torch.tensor([1.2, 2.3], dtype=torch.float32, device='cpu').to('musa')
c = torch.tensor([1.2, 2.3], dtype=torch.float32).musa()

# Also some cuda modules or functions:
torch.backends.mudnn.allow_tf32 = True
event = torch.musa.Event()
stream = torch.musa.Stream()

For distribute training or inference, initialize your process group with backend mccl:

import torch.distributed as dist

dist.init_process_group("mccl", rank=rank, world_size=world_size)

Docker Image

We provide several released docker images and they can be easily found in mcconline, and encourage developers to utilize torch_musa within docker environment.

Pull the docker image with docker pull, create a container with command below and there you go.

# For example, start a S80 docker with Python3.10
docker run -it --privileged \
  --pull always --network=host \
  --env MTHREADS_VISIBLE_DEVICES=all \
  registry.mthreads.com/mcconline/musa-pytorch-release-public:latest /bin/bash

During its initial startup, it performs a self-check, so you can see the MUSA environment is ready or not.

Installation

Prerequisites

Before installing torch_musa, here are some software packages that need to be installed on your machine first:

• MUSA-SDK, including MUSA Driver, musa_toolkit, muDNN and MCCL(S4000 only);
• Math-Libs, including muThrust and muAlg;
• (For Docker users) KUAE Cloud Native Toolkits, including Container-Toolkit, MTML, sGPU;

Run musaInfo to check if the MUSA environment is set correctly, if it outputs error log instead of device information, refer to Trouble Shotting.

From Python wheels

Download torch & torch_musa wheels from our Release Page, please make sure you have all prerequisites installed.

From Source

Firstly, clone the torch_musa repository:

git clone https://github.com/MooreThreads/torch_musa.git
cd torch_musa

then, we need to set MUSA_HOME, PATH, LD_LIBRARY_PATH and PYTORCH_REPO_PATH for building torch_musa:

export MUSA_HOME=path/to/musa/install/path  # defalut value is /usr/local/musa/
export LD_LIBRARY_PATH=$MUSA_HOME/lib:$LD_LIBRARY_PATH
export PATH=$MUSA_HOME/bin:$PATH

# if PYTORCH_REPO_PATH is not set, PyTorch will be downloaded outside this directory when building with build.sh
export PYTORCH_REPO_PATH=/path/to/PyTorch

To build torch_musa, run:

bash build.sh -c  # clean cache then build PyTorch and torch_musa from scratch

Some important building parameters are as follows:

• --torch/-t: build original PyTorch only
• --musa/-m: build torch_musa only
• --debug: build in debug mode
• --asan: build in asan mode
• --clean/-c: clean everything built and build
• --wheel/-w: generate wheels

For example, if one has built PyTorch and only needs to build torch_musa and generate wheel, run:

bash build.sh -m -w

For S80/S3000 users, since the MCCL library is not provided for such architectures, please add USE_MCCL=0 whilst building torch_musa:

USE_MCCL=0 bash build.sh -c

MUSA Supported Repositories

torchvision

For torch_musa v2.7.0 and later, install torchvision from our repository:

git clone https://github.com/MooreThreads/vision -b 0.26.0.post2 --depth 1
cd vision && python setup.py install

Otherwise, install torchvision from torch repository:

git clone https://github.com/pytorch/vision -b ${version} --depth 1
cd vision && python setup.py install

the version depends on torch version, for example you have torch v2.5.0, ${version} should be 0.20.0.

torchaudio

Install torchaudio from torch source:

git clone https://github.com/pytorch/audio.git -b release/${version} --depth 1
cd audio && python setup.py install

the version is same as the torch version.

Other Repositories

Many repositories have supported MUSA backend upstream, like Transformers, Accelerate, you can install them from PyPi with pip install [repo-name].

For others that haven't supported musa, we musified them and put into our GitHub, here's the list:

Each repository can be built and install via python setup.py install or pip install . --no-build-isolation.

If users find any question about these repos, please file issues in torch_musa, and if anyone musify a repository, you can submit a Pull Request that helping us to expand this list.

Trouble Shooting

• torch.musa.is_available() returns False

  • Possible cause: MUSA driver/runtime is not installed or not loaded correctly, or required shared libraries are not found in the current environment.
  • Suggested fix: Make sure MUSA-SDK is installed and available, and check that MUSA_HOME and LD_LIBRARY_PATH (or corresponding paths inside your container) include directories for musa_toolkit/muDNN, etc.

• Import error: ImportError: libmusa...so: cannot open shared object file / missing libmudnn.so / libmccl.so

  • Possible cause: Shared library search path is not configured, or the wheel/package does not match the system libraries.
  • Suggested fix: Configure (example):
    • export MUSA_HOME=/usr/local/musa
    • export LD_LIBRARY_PATH=$MUSA_HOME/lib:$LD_LIBRARY_PATH and ensure your driver/toolchain versions are compatible with the torch_musa version you are using.

• Import error: ImportError: libmkl...so: cannot open shared object file / missing libmkl.so

  • Possible cause: libmkl.so is needed from pytorch, and you could be using pre-built wheel with MKL installed.
  • Suggeseted fix: Uninstall torch, and rebuild it from source (run bash build.sh -t).

• Distributed init fails: dist.init_process_group("mccl", ...) (backend not available / not found)

  • Possible cause: MCCL is not installed, or the current architecture does not support it.
  • Suggested fix: Make sure MCCL is installed (S4000 only). On architectures without MCCL (e.g. S80/S3000), build with USE_MCCL=0 when needed and use a backend that is available in your environment.

• When building from source, PyTorch is downloaded outside the repo / unexpected build location

  • Possible cause: PYTORCH_REPO_PATH is not set.
  • Suggested fix: Set export PYTORCH_REPO_PATH=/path/to/PyTorch before building (see “From Source” above).

• No device visible inside container / “no device” (or similar) at runtime

  • Possible cause: Device nodes are not passed into the container, or device visibility is not configured.
  • Suggested fix: Start the container using the example flags in this README, and ensure MTHREADS_VISIBLE_DEVICES=all (or a specific device ID list) is set.

License

torch_musa has a BSD-style license, as found in the LICENSE file.
