WAS Node Suite v3
WAS Node Suite has been going since 2023 on Civitai and on GitHub, and was among the first packs to put hundreds of nodes into users' hands. WAS-NS has over a million downloads, and is used by thousands of users daily. It has been MIT since the first commit: use it, change it, teach with it, or run it in paid services.
The pack contains 481 nodes for ComfyUI, across images, filters and colour, masking, text and prompts, logic and flow, numbers, latents and sampling, files, animation and video.
See NODES.md for reference.
Consider donating to the project to help me afford caffeine.
Installation
ComfyUI Manager, search for WAS Node Suite v3 and install. This is the recommended route.
Manually, clone into custom_nodes:
cd ComfyUI/custom_nodes
git clone https://github.com/WASasquatch/was-node-suite-comfyui.git
Requires ComfyUI 0.14.0 or newer and Python 3.10+.
That is the whole install. Nothing is installed, downloaded or built, now or on any later start. The pack never runs pip on its own.
The first start takes a second or two longer than the rest. Your config.yaml, the state
database and the wildcard, LUT and view-extension folders are written under
/was-node-suite/, and python compiles the pack to bytecode. An update
recompiles, so it happens once more each time you pull.
One optional group wants packages and ships off: document_export, which lets Save DOC
write .docx, .odt and .pdf.
# portable ComfyUI, from the ComfyUI_windows_portable directory
python_embeded\python.exe -m pip install -r ComfyUI\custom_nodes\was-node-suite-comfyui\requirements\document_export.txt
Then set document_export: true under features: in config.yaml.
docs/CONFIG.md has every group, what it needs and what it gates.
What changed since v2
481 nodes across a package of source files. The pack itself needs no packages, and nothing is
fetched from a git URL. What it bundles ships in the repository with its licence beside it,
listed in docs/THIRD_PARTY.md.
| v2 | v3 | |
|---|---|---|
| Nodes | 220 | 468 |
| Default packages installed | 20 | 0 |
| Installed from a git URL | 3 | 0 |
| Third-party carried in the repository | SAM and BLIP, 75 files of python | 128 files: browser libraries, fonts, eight face cascades, two sets of weights and one network, each with its licence |
| Optional node groups | none | 22 keys in config.yaml, 8 of them off out of the box. Per-node disable group. |
213 of the 220 node ids are unchanged. Four are retired onto replacements, three are removed outright, and the section below says what opens in their place. Face detection, gradient maps, background removal, frame interpolation, seamless textures, colour matching, levels, palettes, masks and deconvolution all run on torch, on ComfyUI's own device, so OpenCV, numba, rembg, timm, scipy, scikit-image, scikit-learn and matplotlib are not installed. Everything else a node reaches for either ships with ComfyUI or belongs to an optional group.
253 new nodes
| Area | New | Area | New |
|---|---|---|---|
| Three.js scenes | 43 | HDR and linear light | 9 |
| Files, archives and documents | 28 | Affine sampling | 8 |
| Logic and flow | 25 | Everything else | 108 |
| Layers | 22 | ||
| Bounds | 10 |
What each area does: FEATURES.md.
Opening a workflow saved before v3
No node id is renamed. Two nodes are now a different node under the same menu name, two ids are gone and another node does the job of each, and ComfyUI offers to swap all four in. Three ids are removed with nothing in their place. Widgets, slot counts, three menu labels and four results changed, and a workflow saved before v3 is carried across as it loads.
Four retired ids. Each one opens listed in ComfyUI's missing-node dialog. Tick it, press the replace button, and the node comes back in place. Leave the dialog and it stays missing. The old name still finds its replacement in the Add Node search.
| Saved as | Comes back as | With |
|---|---|---|
Image Crop Face |
the same name, on a replacement running the same eight cascades | wiring, crop padding, cascade choice, flip setting |
Image Gradient Map |
the same name, on a replacement running the same gradients | wiring and settings |
Load Lora |
Lora Loader (Advanced), same five inputs and three outputs | model and CLIP wired, all three outputs wired, LoRA choice, both strengths |
Number to Text |
Number to String, same NUMBER, INT and FLOAT input, same STRING output | both wires. Neither node has a widget, so nothing is retyped |
The two face and gradient nodes ran through OpenCV, which the pack no longer installs. Their replacements run on ComfyUI's own device and need nothing installed.
Five removed ids. Each opens as a red box where it stood, with its links dropped. There is no replacement for any of them; delete the node.
| Saved as | What it did | What to do |
|---|---|---|
Image Send HTTP |
Posted an image batch to an address | Write the batch with Image Save |
Text Random Prompt |
Read a prompt from lexica.art | Write the prompt, or use Prompt Library |
True Random.org Number Generator |
Drew a seed from RANDOM.ORG | Use Random Number or Seed |
WASDownloadImage |
Read an image from a web address | Save the file, then use Load Image |
WASNoodleSoupPantryRefresh |
Downloaded the Noodle Soup pantry | Nothing. The pantry ships with the pack and seeds the database on first start |
The pack now makes no outbound request of its own from any node.
Widgets and slots, carried across for you. Thirty-six dropdowns reading true and false
are now checkboxes, and fourteen nodes that stopped at four to eight slots now declare
twenty-four or twenty-six, drawing one empty slot below the last one filled. Saved settings are
read back onto the new widgets and everything wired stays wired. The three batchers each gain a
count output below the one they had. Image Save's prefix_as_filename is now
overwrite_mode, ticked where it read true.
Three Custom Material takes a module file. Its javascript box is gone. The node now picks
a .js or .txt module from ComfyUI's input folder or a folder under paths.allow_read, and
the module's header names the textures it wants, which the node's slots then read as. A body
typed into an older workflow is dropped rather than read onto the menu, so open one, put the
body in a file and pick it. Code no longer travels inside a workflow, so a graph from someone
else cannot bring javascript with it. docs/CONFIG.md has the setting
that permits a module to run at all.
Three renamed labels. KSampler is now KSampler (Seed Socket), Seed is
Seed (Number Outputs) and Save Video is Save Video (Advanced), so none shares a name with
a core ComfyUI node. Only the label changed, and the old names still find them in search.
Four changed results.
| Node | What changed | What to do |
|---|---|---|
Image Blending Mode |
26 blend modes instead of 14, in linear light on the GPU, keeping values above white. add now adds the two layers rather than painting image_b over image_a |
A graph using add comes out brighter. Switch it to normal for what it did before |
Image Style Filter |
37 looks, every graded one finished with a halation. The 26 period looks keep the colour their name has always meant | Nothing. A saved workflow opens on the same style |
Mask Erode Region |
Holds the frame edge instead of treating outside the frame as unset | A mask that touched an edge comes out wider. One with a clear margin is unchanged |
Image SSAO (Ambient Occlusion) |
Traces rays across the map as real relief instead of averaging neighbouring pixels, so the shading follows the surface and no longer reacts to the image's own colour. The depth_images input is now height_maps, tile_size is gone, and height_scale, ray_count, step_count and angle_bias set the relief and the tracing. The whole body is float now, so linear light above 1.0 is shaded rather than clipped, and a precision widget writes 8, 16 or 32 bit for EXR Save |
Re-wire the depth map into height_maps, which opens unconnected. The other settings are read back onto the new widgets. Highlight masking now starts off, so the node shades as soon as it is dropped, and strength at 0 leaves the image untouched rather than black |
Nodes
481 nodes across 48 categories. NODES.md carries every input, output and
tooltip, and groups them by the config.yaml switch that gates them:
feature gates.
28 are deprecated, which ComfyUI marks in the Add Node menu, and each names its
replacement. They sit in the nine legacy groups in config.yaml, four of which start off:
docs/CONFIG.md.
Features
FEATURES.md covers what the pack does, by area: masking, layers, bounds,
filters and optics, transforms, colour and LUTs, HDR, instruments, logic and flow, numbers,
text and dictionaries, prompt terminology and styles, files and archives, animation, models
and LoRA, the affine transform, noise shaping, video comparison, execution gating, the
Content Viewer, Three.js scenes and graph plumbing.
Model weights
Nothing is downloaded unless you ask for it. features.network is false out of the box, so a node needing weights it cannot find says so and names the key rather than reaching for the network, and Three Texture URL takes only data: addresses and the pack's own assets.
Let it download. Set network: true under features: in config.yaml.
See docs/MODELS.md for more information.
Configuration
Written for you on first start at /was-node-suite/config.yaml, as a copy of
config.example.yaml with every key at its default and the comment that
explains it. Edit it there as it will survive updates.
docs/CONFIG.md
Third-party code in the pack
The suite is MIT, see LICENSE. It bundles 128 third-party files: three.js and
three-gpu-pathtracer, HugeRTE, Prism.js, KaTeX and Mermaid, the EMA-VFI network, the DejaVu and
Liberation fonts, eight face cascades and two sets of weights. Each keeps its own licence text
in the folder it ships in, and none of it is ever fetched. Every licence permits redistribution.
Versions, copyright lines, which licence covers what and a byte-level account of every bundled
copy: docs/THIRD_PARTY.md.
The software licences place no conditions on what you make with the suite: documents, captions and images you produce are yours. Open RAIL++-M, covering one 8 KB embedding, is the exception. It claims no rights in output but its use restrictions reach any use of that output, including the intrinsic maps Power Preprocessor answers with.
Security
Outbound requests are off out of the box, nothing starts a process or installs a package, and a
node input naming a file is resolved against an allowlist before the filesystem is touched.
What the pack does and does not do, and how to report a vulnerability:
SECURITY.md.
Contributing
Bug reports and feature requests are welcome as issues. For a change to a node, open an issue first, so its inputs and outputs are settled before the code is written. See docs/CONTRIBUTING.md.
